Datasheet >

284699

Among 6 related components, 284699 have related pdf.
Part Number Manufacturer Description Datasheet
284699 ERNI RF Connectors / Coaxial Connectors SMT ML REC AU 50 OHM W/ANTI SLDR WCKNG RL Download
284699 ERNI Electronics 针座连接器 通孔 8 位置 0.050"(1.27mm) Download
284699-1 TE Connectivity 5 位置 体座 连接器 母型,插座 天然 0.250"(6.35mm) Download
284699-2 TE Connectivity 5 位置 体座 连接器 母型,插座 绿色 0.250"(6.35mm) Download
284699-3 TE Connectivity 5 位置 体座 连接器 母型,插座 黄色 0.250"(6.35mm) Download
284699-4 TE Connectivity 5 位置 体座 连接器 母型,插座 红色 0.250"(6.35mm) Download
284699 parameters:

Description

RF Connectors / Coaxial Connectors SMT ML REC AU 50 OHM W/ANTI SLDR WCKNG RL

Parametric
Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerERNI
Reach Compliance Codecompliant
Samacsys DescriptionHeaders & Wire Housings 8P 1.27MM SMT BLACK VERT MALE BCKPLN
Other featuresMINIBRIDGE
Board mount optionsPEG
body width0.276 inch
subject depth0.207 inch
body length0.6 inch
Body/casing typeRECEPTACLE
Connector typeCOMBINATION LINE CONNECTOR
Contact to complete cooperationGOLD
Contact completed and terminatedTin (Sn)
Contact point genderMALE
Contact materialNOT SPECIFIED
contact modeRECTANGULAR
Contact resistance25 mΩ
Contact styleSQ PIN-SKT
DIN complianceNO
Dielectric withstand voltage700VAC V
Durability500 Cycles
empty shellNO
Filter functionNO
IEC complianceNO
maximum insertion force1.0008 N
Insulation resistance10000000000 Ω
insulator materialLIQUID CRYSTAL POLYMER (LCP)
JESD-609 codee3
MIL complianceNO
Manufacturer's serial number284699
Plug contact pitch0.05 inch
Plug informationMULTIPLE MATING PARTS AVAILABLE
Mixed contactsNO
Installation option 1LOCKING
Installation methodSTRAIGHT
Installation typeBOARD
Number of connectorsONE
PCB row number1
Number of rows loaded1
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
OptionsGENERAL PURPOSE
PCB contact patternRECTANGULAR
polarization keyPOLARIZED HOUSING
Rated current (signal)4 A
GuidelineUL
reliabilityCOMMERCIAL
Shell materialLIQUID CRYSTAL POLYMER
Terminal pitch1.27 mm
Termination typeSURFACE MOUNT
Total number of contacts8
UL Flammability Code94V-0
Base Number Matches1
