2SJ529L-E.

Among 2 related components, 2SJ529L-E. have related pdf.

Part Number	Manufacturer	Description	Datasheet
2SJ529L-E	Renata SA	silicon P channel mos fet	Download
2SJ529L-E	Renesas Electronics Corporation	Pch Single Power MOSFET -60V -10A 160mohm DPAK(L)-(2)/TO-251	Download

2SJ529L-E. parameters：

Description

Pch Single Power MOSFET -60V -10A 160mohm DPAK(L)-(2)/TO-251

Parametric

Parameter Name	Attribute value
Brand Name	Renesas
Is it Rohs certified?	conform to
Maker	Renesas(瑞萨电子)
Parts packaging code	DPAK(L)-(2)
package instruction	IN-LINE, R-PSIP-T3
Contacts	4
Manufacturer packaging code	PRSS0004ZD-B4
Reach Compliance Code	compliant
ECCN code	EAR99
Samacsys Confidence	3
Samacsys Status	Released
Samacsys PartID	532752
Samacsys Pin Count	3
Samacsys Part Category	Integrated Circuit
Samacsys Package Category	Transistor Outline, Vertical
Samacsys Footprint Name	PRSS0004ZD-B
Samacsys Released Date	2020-01-28 11:25:15
Is Samacsys	N
Shell connection	DRAIN
Configuration	SINGLE WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage	60 V
Maximum drain current (Abs) (ID)	10 A
Maximum drain current (ID)	10 A
Maximum drain-source on-resistance	0.24 Ω
FET technology	METAL-OXIDE SEMICONDUCTOR
JESD-30 code	R-PSIP-T3
JESD-609 code	e6
Humidity sensitivity level	1
Number of components	1
Number of terminals	3
Operating mode	ENHANCEMENT MODE
Maximum operating temperature	150 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Polarity/channel type	P-CHANNEL
Maximum power dissipation(Abs)	20 W
Maximum pulsed drain current (IDM)	40 A
Certification status	Not Qualified
surface mount	NO
Terminal surface	TIN BISMUTH
Terminal form	THROUGH-HOLE
Terminal location	SINGLE
Maximum time at peak reflow temperature	NOT SPECIFIED
transistor applications	SWITCHING
Transistor component materials	SILICON
Base Number Matches	1
