APF30260

Among 1 related components, APF30260 have related pdf.

Part Number	Manufacturer	Description	Datasheet
APF30260	Panasonic	General Purpose Relays Relays Power, Over 2 Amps - RELAY PWR SPDT 6A 60VDC SIP PCB	Download

APF30260 parameters：

Description

General Purpose Relays Relays Power, Over 2 Amps - RELAY PWR SPDT 6A 60VDC SIP PCB

Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
ECCN code	EAR99
body width	5 mm
body height	15 mm
Body length or diameter	28 mm
Maximum coil current (DC)	0.003 A
Coil operating voltage (DC)	42 V
Coil power	175 mW
Coil release voltage (DC)	3 V
Coil resistance	20570 Ω
Maximum coil voltage (DC)	60 V
Coil/Input Power Type	DC
Contact (AC) maximum rated R load	6A@250VAC
Maximum contact current (AC)	6 A
Maximum contact voltage (AC)	250 V
Contact/Output Power Type	AC
Electrical life	50000 Cycle(s)
Installation features	THROUGH HOLE-STRAIGHT MOUNT
operating hours	8 ms
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
method of packing	BOX; TUBE
physical size	28mm x 5mm x 15mm
Guideline	UL; VDE
Relay action	MOMENTARY
Relay function	SPDT
Relay type	POWER/SIGNAL RELAY
release time	4 ms
seal	WATER PROOF
surface mount	NO
Termination type	SOLDER
Base Number Matches	1
