ASF6204

Among 2 related components, ASF6204 have related pdf.

Part Number	Manufacturer	Description	Datasheet
ASF6204	TE Connectivity	Slide switch 6PDT 6POS FLUSH TOP T/H SLIDE SWITCH	Download
ASF620404	TE Connectivity	SLIDE SWITCH	Download

ASF6204 parameters：

Description

滑动开关 6PDT 6POS FLUSH TOP T/H SLIDE SWITCH

Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Reach Compliance Code	compliant
ECCN code	EAR99
Actuator angle
Actuator color	NATURAL
Actuator type	SLIDE
body width	7.366 mm
body height	4.445 mm
Body length or diameter	25.4 mm
center contact material	COPPER ALLOY
Center contact plating	GOLD OVER NICKEL
Contact (AC) maximum rated R load	0.3A@115VAC
Maximum contact current (AC)	0.3 A
Contact resistance	0.04 mΩ
Maximum contact voltage (AC)	115 V
Dielectric withstand voltage	600VRMS V
Electrical life	15000 Cycle(s)
End contact material	COPPER ALLOY
End contact plating	GOLD OVER NICKEL
Insulation resistance	1000000000 Ω
Manufacturer's serial number	ASF
Installation features	THROUGH HOLE-STRAIGHT
Number of positions	6
Maximum operating temperature	80 °C
Minimum operating temperature	-40 °C
PCB hole count	12
surface mount	NO
switch function	6PDT
Terminal surface	TIN/NICKEL
Terminal length	0.16 inch
Terminal material	COPPER ALLOY
Termination type	SOLDER
Base Number Matches	1
