S4012DTP

Among 2 related components, S4012DTP have related pdf.

Part Number	Manufacturer	Description	Datasheet
S4012DTP	Littelfuse	SCRs 12A 400V	Download
S4012DTP56	Littelfuse	Silicon Controlled Rectifier, 12A I(T)RMS, 400V V(DRM), 400V V(RRM), 1 Element, TO-252AA, ROHS COMPLIANT, PLASTIC, DPAK-3	Download

S4012DTP parameters：

Description

SCRs 12A 400V

Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Parts packaging code	TO-252AA
package instruction	SMALL OUTLINE, R-PSSO-G2
Contacts	3
Reach Compliance Code	unknown
Shell connection	ANODE
Configuration	SINGLE
Critical rise rate of minimum off-state voltage	250 V/us
Maximum DC gate trigger current	20 mA
Maximum DC gate trigger voltage	1.5 V
Maximum holding current	40 mA
JEDEC-95 code	TO-252AA
JESD-30 code	R-PSSO-G2
JESD-609 code	e3
On-state non-repetitive peak current	120 A
Number of components	1
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Maximum rms on-state current	12 A
Off-state repetitive peak voltage	400 V
Repeated peak reverse voltage	400 V
surface mount	YES
Terminal surface	Matte Tin (Sn)
Terminal form	GULL WING
Terminal location	SINGLE
Maximum time at peak reflow temperature	40
Trigger device type	SCR
Base Number Matches	1
