WSLP1206R0100FEA.

Among 1 related components, WSLP1206R0100FEA. have related pdf.

Part Number	Manufacturer	Description	Datasheet
WSLP1206R0100FEA	Vishay	RESISTOR, CURRENT SENSE, METAL STRIP, 1 W, 1 %, 75 ppm, 0.01 ohm, SURFACE MOUNT, 1206, CHIP, GREEN	Download

WSLP1206R0100FEA. parameters：

Description

RESISTOR, CURRENT SENSE, METAL STRIP, 1 W, 1 %, 75 ppm, 0.01 ohm, SURFACE MOUNT, 1206, CHIP, GREEN

Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Vishay(威世)
package instruction	SMT, 1206
Reach Compliance Code	compliant
ECCN code	EAR99
Samacsys Confidence
Samacsys Status	Released
Samacsys PartID	239087
Samacsys Pin Count	2
Samacsys Part Category	Resistor
Samacsys Package Category	Other
Samacsys Footprint Name	RESC3216X88N
Samacsys Released Date	2017-01-12 11:18:21
Is Samacsys	N
Other features	ANTI-SULFUR
structure	Chip
JESD-609 code	e3
Installation features	SURFACE MOUNT
Number of terminals	2
Maximum operating temperature	170 °C
Minimum operating temperature	-65 °C
Package height	0.635 mm
Package length	3.2 mm
Package shape	RECTANGULAR PACKAGE
Package form	SMT
Package width	1.6 mm
method of packing	TR, EMBOSSED PLASTIC, 7 INCH
Rated power dissipation(P)	1 W
Rated temperature	70 °C
Guideline	AEC-Q200
resistance	0.01 Ω
Resistor type	FIXED RESISTOR
size code	1206
surface mount	YES
technology	METAL STRIP
Temperature Coefficient	75 ppm/°C
Terminal surface	Matte Tin (Sn) - with Nickel (Ni) barrier
Terminal shape	WRAPAROUND
Tolerance	1%
Operating Voltage	0.1 V
Base Number Matches	1
