NEW OPTIONS
RJ45
HDMI
Toggle, Rocker and
Momentary Switches
¼” TS and TRS Jacks
The easiest way to create
custom I/O panels and wall plates
Compatible with Switchcraft®
QGPK Series rack panels and
WP Series wall plates
All connectors fit into a standard
XLR panel cutout
Available in black or
nickel finishes
Custom combinations of
EH Series connectors can
be quickly loaded into any of
our 1RU (1x16), 1.5RU
(1x16), or 2RU (2x16)
QGPK Series panels
Available individually or bagged
with mounting screws
The EH Series is an extensive line of panel mount audio,
video and data connectors used to create custom I/O
panels and wall plates for A/V, pro audio, broadcast, mobile
production and post production installations.
Please visit www.switchcraft.com for the most up-to-date product specifications. Made in USA.
EH SERIES • AUDIO, VIDEO, DATA
NEW PRODUCT BULLETIN 598
XLR (3 Pin, Female, No Latch)
XLR (3 Pin, Female)
XLR (3 Pin Male)
XLR (3 Pin Gold, Male)
1/4” TS (Mono)
1/4” TRS (Stereo)
1/4” Locking TRS (Stereo)
3.5mm TRS (1/8” Stereo)
PS/2 (6 Pin DIN)
S-Video (4 Pin DIN)
BNC
BNC to RCA
RCA to BNC
RCA to RCA
RJ45 (CAT 6)
RJ45 (CAT 6) Shielded
Please visit www.switchcraft.com for the most up-to-date product specifications. Made in USA.
EH SERIES • AUDIO, VIDEO, DATA
NEW PRODUCT BULLETIN 598
Firewire 800
Firewire 400
USB (A to B)
USB (B to A)
9 Pin DSUB
(Female to Female)
9 Pin DSUB
(Male to Female)
15 Pin DSUB
(Female to Female)
15 Pin DSUB
(Male to Female)
Fiber Optic (LC)
Fiber Optic (SC)
Fiber Optic (ST)
Fiber Optic (TOSLINK)
Switch (Momentary Pushbutton)
Switch (Toggle)
Switch (Rectangular Rocker)
HDMI
Please visit www.switchcraft.com for the most up-to-date product specifications. Made in USA.
EH SERIES • AUDIO, VIDEO, DATA
NEW PRODUCT BULLETIN 598
F Type
Blank Hole Covers
Part
Number
WP1S
WP1S1
WP1S1P
WP1B1
WP1B1P
WP1S2
WP1S2P
WP1B2
WP1B2P
WP2S4
WP2S4P
WP2B4
WP2B4P
Gang
Size
1
1
1
1
1
1
1
1
1
2
2
2
2
Finish
Stainless Steel
Stainless Steel
Stainless Steel
Black Aluminum
Black Aluminum
Stainless Steel
Stainless Steel
Black Aluminum
Black Aluminum
Stainless Steel
Stainless Steel
Black Aluminum
Black Aluminum
EH Connector
Holes
0
1
1
1
1
2
2
2
2
4
4
4
4
Connector
Mounting Hole
None
Ø0.138
#4-40 Thread
Ø0.138
#4-40 Thread
Ø0.138
#4-40 Thread
Ø0.138
#4-40 Thread
Ø0.138
#4-40 Thread
Ø0.138
#4-40 Thread
W P S E R I E S WA L L P L AT E S
WP Series wall plates are the perfect solution for anyone
requiring custom connector configurations on standard
size wall plates. Options include single and double gang
with 0, 1, 2, and 4 connector holes. Plates are available
in brushed stainless steel or anodized black aluminum
and with standard or tapped 4-40 connector mounting
holes. Tapped mounting holes allow connectors to be
screwed directly into the plate without the use of a nut
(front mount only).
Q - G ® PA N E L O P T I O N S
QGPK1B440
Empty Q-G® Rack Panels
QGPK1B
QGPK1B440
QGPK2B
QGPK2B440
QGPK3B
QGPK3B440
Rack Height
1RU
1RU
1.5RU
1.5RU
2RU
2RU
Number of Knockouts
1X16
1X16
1X16
1X16
2X16
2X16
Tapped 4-40 Holes
NO
YES
NO
YES
NO
YES
Please visit www.switchcraft.com for the most up-to-date product specifications. Made in USA.
