Relay Module - PLC-RSC-220DC/21AU - 2987286
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
PLC-INTERFACE, consisting of PLC-BSC.../21 basic terminal block with screw connection and plug-in
miniature relay with multi-layer gold contact, for mounting on DIN rail NS 35/7,5, 1 PDT, input voltage 220 V
DC
Key Commercial Data
Packing unit
GTIN
GTIN
4046356337267
10 pc
Technical data
Note
Utilization restriction
EMC: class A product, see manufacturer's declaration in the download
area
Dimensions
Width
Height
Depth
6.2 mm
80 mm
94 mm
Ambient conditions
Ambient temperature (operation)
Ambient temperature (storage/transport)
-25 °C ... 55 °C
-40 °C ... 85 °C
Coil side
Nominal input voltage U
N
Typical input current at U
N
Typical response time
Typical release time
Coil voltage
Protective circuit
220 V DC
3 mA
7 ms
15 ms
60 V DC
Reverse polarity protection Polarity protection diode
10/28/2018 Page 1 / 4
https://www.phoenixcontact.com/pi/products/2987286
Relay Module - PLC-RSC-220DC/21AU - 2987286
Technical data
Coil side
Surge protection Damping diode
Operating voltage display
Power dissipation for nominal condition
Yellow LED
0.66 W
Contact side
Contact type
Type of switch contact
Contact material
Maximum switching voltage
Minimum switching voltage
Min. switching current
Maximum inrush current
Limiting continuous current
Interrupting rating (ohmic load) max.
1 PDT
Single contact
AgSnO, hard gold-plated
30 V AC
36 V DC
100 mV (at 10 mA)
1 mA (at 24 V)
50 mA
50 mA
1.2 W (at 24 V DC)
Contact side (with destroyed gold layer)
Note
Maximum switching voltage
Minimum switching voltage
Min. switching current
the following values are applicable if a gold layer is destroyed
250 V AC/DC
5 V (at 100 mA)
10 mA (at 12 V)
Connection data input side
Connection name
Connection method
Stripping length
Screw thread
Conductor cross section solid
Conductor cross section flexible
Coil side
Screw connection
8 mm
M3
0.14 mm² ... 2.5 mm²
0.14 mm² ... 2.5 mm²
0.2 mm² ... 2.5 mm² ()
2x 0.5 mm² ... 1.5 mm² ()
Conductor cross section AWG
26 ... 14
Connection data output side
Connection name
Connection method
Stripping length
Screw thread
Conductor cross section solid
Conductor cross section flexible
Contact side
Screw connection
8 mm
M3
0.14 mm² ... 2.5 mm²
0.14 mm² ... 2.5 mm²
0.2 mm² ... 2.5 mm² ()
2x 0.5 mm² ... 1.5 mm² ()
Conductor cross section AWG
26 ... 14
10/28/2018 Page 2 / 4
https://www.phoenixcontact.com/pi/products/2987286
Relay Module - PLC-RSC-220DC/21AU - 2987286
Technical data
General
Test voltage relay winding/relay contact
Operating mode
Degree of protection
Mechanical service life
Mounting position
Assembly instructions
4 kV
rms
(50 Hz, 1 min.)
100% operating factor
IP20 (Relay base)
2x 10 cycles
any
In rows with zero spacing
7
Standards and Regulations
Connection in acc. with standard
Designation
Standards/regulations
CUL
Air clearances and creepage distances between the power circuits
IEC 60664
IEC 60664A
DIN VDE 0110
DIN EN 50178/VDE 0160
IEC 60255/DIN VDE 0435 (in relevant parts)
Rated surge voltage
Insulation
4 kV
Basic insulation
Safe isolation, reinforced insulation, and 6 kV between input circuit and
output contact current paths
Environmental Product Compliance
REACh SVHC
China RoHS
Lead 7439-92-1
Environmentally Friendly Use Period = 50
For details about hazardous substances go to tab “Downloads”,
Category “Manufacturer's declaration”
Approvals
Approvals
Approvals
UL Listed / UL Recognized / cUL Recognized / cUL Listed / EAC / RC FRT / cULus Recognized / cULus Listed
Ex Approvals
Approval details
UL Listed
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
FILE E 172140
10/28/2018 Page 3 / 4
https://www.phoenixcontact.com/pi/products/2987286
Relay Module - PLC-RSC-220DC/21AU - 2987286
Approvals
UL Recognized
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
FILE E 238705
cUL Recognized
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
FILE E 238705
cUL Listed
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
FILE E 172140
EAC
RU C-
DE.A*30.B.01082
RC FRT
B.00094
cULus Recognized
cULus Listed
