Product data sheet
Characteristics
ZCD27
limit switch body ZCD - compact - 2NC - slow-
break
Product availability: Non-Stock - Not normally stocked in distribution facility
Main
Commercial Status
Range of product
Series name
Product or component
type
Device short name
Design
Body type
Associated head
Commercialised
OsiSense XC
Standard compact
Limit switch body
ZCD
Compact
Fixed
ZCE01
ZCE02
ZCE05
ZCE06
ZCE07
ZCE08
ZCE10
ZCE11
ZCE13
ZCE14
ZCE21
ZCE24
ZCE27
ZCE28
ZCE29
ZCE62
ZCE63
ZCE64
ZCE65
ZCE66
ZCE67
ZCEH0
ZCEH2
Zamak
2
2 NC
Slow-break, simultaneous
The information provided in this documentation contains general descriptions and/or technical characteristics of the performance of the products contained herein.
This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications.
It is the duty of any such user or integrator to perform the appropriate and complete risk analysis, evaluation and testing of the products with respect to the relevant specific application or use thereof.
Neither Schneider Electric Industries SAS nor any of its affiliates or subsidiaries shall be responsible or liable for misuse of the information contained herein.
Body material
Number of poles
Contacts type and
composition
Contacts operation
Complementary
Associated connection component
ZCDEF12
ZCDEG11
ZCDEG13
ZCDEN12
ZCDEP16
ZCDEP20
Screw-clamp terminals, clamping capacity: 1 x 0.5...2 x 2.5 mm²
Zb
Silver plated contacts
With
19.69 ft/s (6 m/s)
R300, DC-13 (Ue = 250 V, Ie = 0.1 A) conforming to EN/IEC 60947-5-1 appendix
A
B300, AC-15 (Ue = 240 V, Ie = 1.5 A) conforming to EN/IEC 60947-5-1 appendix
A
Electrical connection
Contacts insulation form
Contacts material
Positive opening
Minimum actuation speed
Contact code designation
Feb 29, 2016
1
[Ui] rated insulation voltage
300 V conforming to CSA C22.2 No 14
500 V degree of pollution 3 conforming to IEC 60947-1
300 V conforming to UL 508
6 kV conforming to IEC 60947-1
6 kV conforming to IEC 60664
10 A by gG cartridge fuse
5000000 cycles, DC-13 48 V, 9 W, operating rate: < 60 cyc/mn, load factor: 0.5
conforming to IEC 60947-5-1 appendix C
5000000 cycles, DC-13 24 V, 13 W, operating rate: < 60 cyc/mn, load factor: 0.5
conforming to IEC 60947-5-1 appendix C
5000000 cycles, DC-13 120 V, 7 W, operating rate: < 60 cyc/mn, load factor: 0.5
conforming to IEC 60947-5-1 appendix C
1.22 in (31 mm)
2.56 in (65 mm)
1.18 in (30 mm)
0.31 lb(US) (0.14 kg)
[Uimp] rated impulse withstand voltage
Short circuit protection
Electrical durability
Width
Height
Depth
Product weight
Environment
Product compatibility
Ambient air temperature for operation
Ambient air temperature for storage
XCKD
-13...158 °F (-25...70 °C)
-40...158 °F (-40...70 °C)
Ordering and shipping details
Category
Discount Schedule
GTIN
Nbr. of units in pkg.
Package weight(Lbs)
Product availability
Returnability
Country of origin
22418 - LIMIT SWITCH,IEC,XCKP&XCKT
T
00785901952732
1
0.80
Non-Stock - Not normally stocked in distribution facility
Y
ID
Offer Sustainability
Sustainable offer status
RoHS
REACh
Product environmental profile
Product end of life instructions
Green Premium product
Compliant - since 1103 -
Available
Schneider Electric declaration of conformity
Reference not containing SVHC above the threshold
Download Product Environmental
Need no specific recycling operations
Contractual warranty
Period
18 months
