Surface Mount Resistor Network
FEATURES
•
High Density Packaging
•
Low Profile
•
Inputs/Outputs Available
•
•
•
•
•
•
•
Series 753
- Single Row Terminations [SRT] – 08, 09, 10, 12
- Dual Row Terminations [DRT] – 16, 18, 20, 24
Nickel Barrier Solder-Coated Pads
Designed for Visual Inspection of Solder Joints
Designed for Board Cleaning
Application Specific Circuits are Available
Compatible with Solder Reflow Process
Tape and Reel Packaging
RoHS Compliant in Accordance with EU Directive 2005/95/EC
- Lead-Free Termination Finish
- Exemption 5 for Pb in glass material and resistor elements
ORDERING INFORMATION
753
NUMBER OF PINS
SRT
08 =
09 =
10 =
12 =
DRT
16 =
18 =
20 =
24 =
8 pads
9 pads
10 pads
12 pads
16
18
20
24
pads
pads
pads
pads
P
PACKAGING
Blank = Bulk Pack [250 pcs.]
TR7 = Tape & Reel, 7" reel
TR13 = Tape & Reel, 13" reel
RoHS COMPLIANT
Lead Finish: Matte Sn over
Ni barrier on Ag thick film.
TOLERANCE
Schematic 1 & 3
J = ±5%
G = ±2% [Std]
F = ±1%
D = ±1/2%
Schematic 5
Tolerance code is not added for
dual terminator configuration.
Standard tolerance is ±2%.
SCHEMATIC
1 - Bussed Circuit
3 - Isolated Circuit
5 - Dual Terminator Circuit
RESISTOR CODE
Refer to tables on Page 2.
[Codes are 3 - 4 characters.]
Notes:
1. No dashes or spaces to appear in part number.
2. Example Part Numbers;
Tape & Reel, 753091103GPTR13.
Bulk, 753103221GP.
Dual Terminator, 753165191APTR7.
Not all performance combinations and resistor values may be available.
Contact your local CTS Representative or CTS Customer Service for availability.
Document No. 008-0352-0
Page 1 - 4
Rev. B
www.ctscorp.com
Surface Mount Resistor Network
ORDERING INFORMATION
AVAILABLE RESISTOR VALUES & EIA CODES
Ohms Code Ohms Code Ohms Code Ohms
0
000X
68
680
470
471
3.3K
10
100
75
750
510
511
3.9K
12
120
82
820
560
561
4.7K
15
150
100
101
680
681
5.1K
18
180
110
111
820
821
5.6K
22
220
120
121
1K
102
6.8K
27
270
150
151
1.2K
122
8.2K
33
330
180
181
1.5K
152
10K
39
390
220
221
1.8K
182
12K
47
470
270
271
2.0K
202
15K
51
510
330
331
2.2K
222
18K
56
560
390
391
2.7K
272
22K
Code
332
392
472
512
562
682
822
103
123
153
183
223
Ohms
27K
33K
39K
47K
51K
56K
68K
82K
100K
120K
150K
180K
Code
273
333
393
473
513
563
683
823
104
124
154
184
Ohms
220K
270K
330K
390K
470K
510K
560K
680K
820K
1M
Code
224
274
334
394
474
514
564
684
824
105
Series 753
DUAL TERMINATOR RESISTOR VALUES – Schematic 5
Standard CTS Dual Terminator products contain 2[N-2] resistors of two different values with resistor value connected to a common buss. The part
number includes the EIA Code value of the Thevenin equivalent resistances of R
1
and R
2
. The Thevenin equivalent resistance is calculated in the
following way: [The suffix letter relates only to the sequence of variations that equal the same equivalent resistance.]
R
EQ
= R
1
*R
2
/(R
1
+ R
2
)
Example
753095131A
753095191A
753095131C
R
1
= 220 Ohms
R
1
= 330 Ohms
R
1
= 180 Ohms
R
2
= 330 Ohms
R
2
= 470 Ohms
R
2
= 470 Ohms
R
EQ
= 132 Ohms
R
EQ
= 194 Ohms
R
EQ
= 130 Ohms
[Pad 1 is common to R
2
and Pin N is common to R
1
.]
R1
R2
Ohms
25
50
30
50
30
620
33
4.7K
36
620
43
620
68
189
75
620
80
220
81
130
81
2.2K
100 200
100 430
100 150
106 169
200 1.5K
220 330
220 270
220 220
240 170
240 620
250 250
270 470
270 180
271 131
330 470
Thevenin
Equivalent
17 ohms
19 ohms
29 ohms
33 ohms
34 ohms
40 ohms
50 ohms
67 ohms
59 ohms
50 ohms
78 ohms
67 ohms
81 ohms
60 ohms
65 ohms
176 ohms
132 ohms
121 ohms
110 ohms
100 ohms
173 ohms
125 ohms
171 ohms
108 ohms
88 ohms
194 ohms
CTS Code
150A
190A
290A
330A
340A
400A
500B
670A
590A
500A
780A
670B
810A
600A
650A
171D
131A
121B
111D
101C
171C
131B
171A
111C
880A
191A
R1
R2
Ohms
330 680
330 390
330 220
330 330
360 720
360 600
390 620
470
1K
470 680
470 940
500 500
560 910
110 220
118 178
120 200
120 180
120 120
150 150
160 260
160 240
160 270
162 260
180 300
180 470
180 390
180 270
Thevenin
Equivalent
222 ohms
179 ohms
132 ohms
165 ohms
240 ohms
225 ohms
239 ohms
320 ohms
278 ohms
313 ohms
250 ohms
347 ohms
73 ohms
71 ohms
75 ohms
72 ohms
60 ohms
75 ohms
99 ohms
96 ohms
100 ohms
100 ohms
113 ohms
130 ohms
123 ohms
108 ohms
CTS Code
221A
181A
131D
171B
241B
231A
241A
321A
281A
311A
251A
351A
730A
710A
750B
720A
600B
750A
990A
960A
101D
101B
111B
131C
121A
111A
Thevenin
R3
R4
Ohms
Equivalent
180 220
99 ohms
560
1K
359 ohms
680
1K
405 ohms
750 750
375 ohms
750 2.3K
566 ohms
1K
3.3K
767 ohms
1K
2K
667 ohms
1.1K 2.2K
733 ohms
1.2K 1.2K
600 ohms
1.5K 1.5K
750 ohms
1.5K 3.3K
1031 ohms
2K
2K
1000 ohms
2.2K 5.6K
1579 ohms
2.2K 4.4K
1467 ohms
2.2K 3.3K
1320 ohms
3K
6.2K
2022 ohms
3K
2K
1200 ohms
3.3K 4.7K
1939 ohms
3.9K 3.3K
1788 ohms
4.7K 22K
3873 ohms
5K
5K
2500 ohms
6.8K 22K
5194 ohms
10K 51K
8361 ohms
50K 100K 33,333 ohms
CTS Code
101A
361A
401A
381A
571A
771A
671A
731A
601A
751A
102A
102B
162A
152A
132A
202A
122A
192A
182A
392A
252A
522A
842A
333A
1. All tolerances +/-2%.
2. Other values available on request.
3. Suffix letter has no significance - assigned in sequential order.
Document No. 008-0352-0
Page 2 - 4
Rev. B
Surface Mount Resistor Network
PACKAGING INFORMATION
Tape & Reel
Reel Diameter
Tape Width
Tape Pitch
No. Parts/Reel
7"
13"
16mm
Series 753
4mm
1,000 5,000
ELECTRICAL CHARACTERISTICS
GENERAL REQUIREMENTS
Resistance Range:
Standard: 10 Ohms to 1M Ohms
Operating Temperature Range:
-55°C to +125°C
Temperature Coefficient:
Standard: ±200ppm/°C
Resistance Tolerance:
Standard: ±2% or 0.5 Ohms [whichever is greater]
Special: ±1% or 0.3 Ohms [whichever is greater]
Dielectric Strength:
100 V
AC
Maximum Operating Voltage:
25 V, not to exceed rated power
POWER RATING
SRT
DRT
@25°C
@70°C
[Total Network Power, number of inputs/outputs (Watts)]
8 Pad
-
0.60W
0.40W
9 Pad
-
0.64W
0.43W
10 Pad
-
0.68W
0.45W
12 Pad
-
0.82W
0.55W
-
16 Pad
0.60W
0.40W
-
18 Pad
0.64W
0.43W
-
20 Pad
0.68W
0.45W
-
24 Pad
0.82W
0.55W
MAXIMUM RESISTOR POWER
[Not to exceed total network power]
Schematic
@25°C
@70°C
1
0.06W
0.04W
3
0.12W
0.08W
5
0.06W
0.04W
CIRCUIT TYPES
BUSSED SRT [Schematic 1]
ISOLATED SRT [Schematic 3]
(Not Available in 9 Pads Configuration)
DUAL TERMINATOR SRT [Schematic 5]
(Not Available in DRT)
BUSSED DRT [Schematic 1]
ISOLATED DRT [Schematic 3]
(Not Available in 18 Pads Configuration)
Document No. 008-0352-0
Page 3 - 4
Rev. B
Surface Mount Resistor Network
MECHANICAL SPECIFICATION
PACKAGE DRAWING
No. of Pads
"A" Dimension
SRT/DRT
mm
inch
08/16
6.22 ±0.12
0.245 ±0.005
09/18
6.86 ±0.12
0.270 ±0.005
10/20
7.49 ±0.12
0.295 ±0.005
12/24
8.76 ±0.12
0.345 ±0.005
Notes:
1. Pad termination (e3). Barrier plating is nickel (Ni) over silver (Ag) thick film pad with Matte tin (Sn) finish.
2. Reflow conditions per JEDEC-J-STD-020, +260°C maximum.
3. MSL = 1.
Series 753
Dimension
B
C
D
E
F
G
H
mm
2.41 ±0.12
2.03 ±0.12
0.64 ±0.12
0.71 ±0.12
0.33 ±0.13
0.08 ±0.14
0.89 Ref.
inch
0.095 ±0.005
0.080 ±0.005
0.025 ±0.005
0.028 ±0.005
0.013 ±0.003
0.003 ±0.002
0.035 Ref.
RECOMMENDED LAND PATTERN
Dimension
mm
753
in.
Recommended Land Pattern
D
P
L
W
1.27
0.64
3.05
0.43
0.05
0.025
0.12
0.017
J
0.89
0.035
S
0.51
0.02
DRT Solder Paste Stencil Opening
Dimension
K
Sw
A
mm
0.51
0.30
1.32
4 mil
in.
0.02
0.012
0.052
mm
0.28
0.30
1.47
6 mil
in.
0.011
0.012
0.058
SRT Solder Paste Stencil Opening
Dimension
K
Sw
A
mm
2.75
0.30
4 mil
NA
in.
0.108
0.012
mm
1.72
0.30
6 mil
NA
in.
0.068
0.012
Q
0.15
0.006
0.15
0.006
Q
0.15
0.006
0.15
0.006
Document No. 008-0352-0
Page 4 - 4
Rev. B
