HTS
www.vishay.com
Vishay Sfernice
High Ohmic Values (up to 100 G), High Voltage Resistors
(up to 50 kV) Thick Film Technology
FEATURES
• Core: high purity ceramic
• Coating: epoxy
• Termination: standard lead material is solder
coated copper
• Climatic category: -55 °C / +155 °C / 56 days
• High ohmic values: up to 100 G
• High voltage application: up to 50 kV
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
DIMENSIONS
in millimeters
SERIES
25 min.
ØE
A
7 ± 0.2
8.5 ± 0.5
14 ± 1
23 ± 2
47 ± 2
29 ± 2
47 ± 2
23 ± 2
32 ± 2
47 ± 2
72 ± 2
100 ± 2
ØB
1.6 ± 0.2
2.2 ± 0.2
3.5 ± 0.3
4.5 ± 0.3
4.5 ± 0.3
6.5 ± 0.5
4.5 ± 0.5
Ø E ± 0.1
0.6
WEIGHT IN
g
0.24
0.29
0.67
1.23
4.60
5.27
A
ØB
25 min.
Ø a ± 0.02
58
63
68
523
547
729
45° chamfer
max. 0.25 mm deep
4
L max.
4
747
923
932
947
972
9100
0.8
7.18
8.5 ± 0.5
STANDARD ELECTRICAL SPECIFICATIONS
MODEL
HTS58
HTS63
HTS68
HTS523
HTS547
HTS729
HTS747
HTS923
HTS932
HTS947
HTS972
HTS9100
RESISTANCE
RANGE
200 to 200M
1K to 500M
1K to 2.5G
1K to 5G
1K to 50G
1K to 15G
1K to 30G
1K to 15G
1K to 30G
1K to 50G
1K to 100G
1K to 100G
RATED POWER
P
70 °C
W
0.25
0.5
1
1
1.5
2
2.5
2
2.5
3
4
5
LIMITING ELEMENT
VOLTAGE
V
500
1K
2K
5K
15K
10K
15K
8K
15K
20K
30K
50K
TOLERANCE
±%
0.5, 1, 2, 5, 10
0.5, 1, 2, 5, 10
0.5, 1, 2, 5, 10
0.5, 1, 2, 5, 10
0.5, 1, 2, 5, 10
0.5, 1, 2, 5, 10
0.5, 1, 2, 5, 10
0.5, 1, 2, 5, 10
0.5, 1, 2, 5, 10
0.5, 1, 2, 5, 10
0.5, 1, 2, 5, 10
0.5, 1, 2, 5, 10
TEMPERATURE
COEFFICIENT
± ppm/°C
150
150
150
150
150
150
150
150
150
150
150
150
CRITICAL
RESISTANCE
()
1M
2M
4M
25M
150M
50M
90M
32M
90M
133.3M
225M
500M
Revision: 06-Mar-17
Document Number: 52014
1
For technical questions, contact:
sferfixedresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
HTS
www.vishay.com
Vishay Sfernice
HTS
68
1W
HTS
523
1W
HTS
547
1.5 W
HTS
729
2W
HTS
747
2.5 W
HTS
923
2W
HTS
932
2.5 W
HTS
947
3W
1 k
100 M
1 k
1 G
1 k
10 G
1 k
50 G
20 kV
HTS
972
4W
HTS
9100
5W
TECHNICAL SPECIFICATIONS
SERIES AND STYLES
Power Rating
at +70 °C
± 0.5 %
HTS
58
0.25 W
HTS
63
0.5 W
200
Ohmic Range
100 M 1 k
1 k
1 k
1 k
in Relation to ± 1 %
250 M 500 M 500 M 1 G
•
Temperature
Coefficient
1 k
±2%
± 150 ppm/°C
10 G
1 k
1 k
1 k
1 k
•
Tolerance
200 M 500 M 2.5 G 5 G
±5%
1 k
± 10 %
50 G
Limiting Element
Voltage
Critical Resistance
0.5 kV
1 M
1 kV
2 M
2 kV
4 M
5 kV
15 kV
1 k
1 k
1 k
1 k
1 k
1 k
1 k
1 k
100 M 100 M 100 M 100 M 100 M 100 M 100 M 100 M
1 k
1 G
1 k
10 G
1 k
15 G
10 kV
1 k
1 G
1 k
10 G
1 k
30 G
15 kV
90 M
1 k
1 G
1 k
10 G
1 k
15 G
8 kV
32 M
1 k
1 G
1 k
10 G
1 k
30 G
15 kV
1 k
1 k
100 M 100 M
1 k
1 G
1 k
10 G
1 k
1 G
1 k
10 G
1 k
1 k
100 G 100 G
30 kV
50 kV
25 M 150 M 50 M
90 M 133.3 M 225 M 500 M
MARKING
GEKA trade-mark, series, style, nominal resistance (in
),
tolerance (in %), letter P for TCR ± 150 ppm/°C, manufacturing date.
Because of lack of space, small styles are marked with ohmic value (in
),
tolerance (in %) and letter P.
ORDERING INFORMATION
HTS
MODEL
63
SIZE
1M27
OHMIC VALUE
0.5 %
TOLERANCE
150 ppm/°C
TEMPERATURE
COEFFICIENT
P: Standard: ± 150 ppm/°C
AM500
PACKAGING
e1
LEAD (Pb)-FREE
GLOBAL PART NUMBER INFORMATION
H
T
S
0
0
6
3
1
2
7
4
D
P
A
2
0
GLOBAL
MODEL
HTS
STYLE
HTS:
58 to 9100
OHMIC VALUE
The first three digits are
significant figures and the
last digit specifies the
number of zeros to follow.
R designates decimal point.
5104
= 5.1 M
3303
= 330 k
1276
= 127 M
...
TOLERANCE
D
= 0.5 %
F
=1%
G
=2%
J
=5%
K
= 10 %
TEMPERATURE
COEFFICIENT
P
= 150 ppm
K
= 100 ppm
PACKAGING
B15
= blister
(20 pieces)
B19
= blister
(30 pieces)
A18
= ammopack
(400 pieces)
A20
= ammopack
(500 pieces)
B17
= blister
(25 pieces)
R10
= reel
(500 pieces)
as applicable
SPECIAL
As applicable
Revision: 06-Mar-17
Document Number: 52014
2
For technical questions, contact:
sferfixedresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
