Crystal unit
Product Number (please contact us
)
Q22FA1280xxxx18
MHz RANGE CRYSTAL UNIT
FA - 128
•Nominal
frequency range
•External
dimensions
•Overtone
order
•Applications
:
16 MHz to 54 MHz
:
2.0 × 1.6 × 0.5 mm
:
Fundamental
:
Mobile phone, Bluetooth, W-LAN
:
ISM band radio, Clock for MPU
Actual size
Specifications (characteristics)
Item
Nominal frequency range
Storage temperature range
Operating temperature range
Level of drive
Frequency tolerance
(standard)
Frequency versus
temperature characteristics
(standard)
Load capacitance
Motional resistance (ESR)
Frequency aging
Symbol
f_nom
T_stg
T_use
DL
f_tol
f_tem
C
L
R
1
f_age
Specifications
For RF Reference
For Clock
16.000 MHz to 54.000 MHz
-40
°C
to +125
°C
-40
°C
to +85
°C
(+105
°C)
100
µW
Max.
200
µW
Max.
±10 ×
10
±10 ×
10
-6
Conditions / Remarks
Fundamental
Please contact us about available frequencies.
Storage as single product.
Please contact us about +85
°C
< T_use
*1
±30 ×
10
±30 ×
10
-6
Recommended: 1 to 100
µW
+25
°C,
Please contact us for requirements
not listed in this specifications.
-20
°C
to +75
°C,
Please contact us for
requirements not listed in this specifications.
-6
*1
-6
6 pF to
∞
Please specify.
As per table below
-20
°C
to +75
°C
-6
-6
±1 ×
10 / year Max.
±5 ×
10 / year Max. +25
°C,
First year
*1
Please contact us for available frequency tolerances as they are dependent upon the nominal frequency.
Motional resistance (ESR)
Frequency
16.0 MHz
≤
f_nom < 18.0 MHz
18.0 MHz
≤
f_nom < 20.0 MHz
20.0 MHz
≤
f_nom < 24.0 MHz
24.0 MHz
≤
f_nom < 26.0 MHz
26.0 MHz
≤
f_nom
≤
54.0 MHz
Product name
(Standard form)
FA-128
Motional resistance
200
Ω
Max.
150
Ω
Max.
100
Ω
Max.
80
Ω
Max.
60
Ω
Max.
24.000000MHz
12.0 +10.0-10.0
-6
Model
Frequency
Load capacitance(pF)
Frequency tolerance(
×
10
,
+25
°C)
In addition to the above mentioned specification item, please specify frequency temperature characteristics
and operating temperature range in case of inquiry.
External dimensions
2.0±0.1
#4
#3
(Unit:mm)
Footprint (Recommended)
(Unit:mm)
1.6±0.1
2600M
E 6 6R A
#1
#2
1.45
0.5 Max.
0.65
#1
0.6
#2
0.45 0.5
#4
#1
Internal connection
(TOP VIEW )
#3
#2
1.15
0.85
C 0.2 M in.
0.95
#4
#3
#2 and #4 are conn ected to the cover.
(Please connect to ground)
