ALUMINUM ELECTROLYTIC CAPACITORS
UUT
Specifications
Item
6mmL Chip Type , Wide Temperature Range
Chip type with load life 2000 hours at +105
°C
.
Designed for surface mounting on high density PC board.
Applicable to automatic mounting machine fed with carrier tape.
Compliant to the RoHS directive (2011/65/EU).
UUA
Long Life
UUX
Higher C/V
UUT
Long Life
UWT
Performance Characteristics
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
Tangent of loss angle (tan
δ)
–55 to +105°C
4 to 50V
1 to 100µF
± 20% at 120Hz, 20°C
After 2 minutes' application of rated voltage at 20°C, leakage current is not more than 0.01 CV or 3 (µA) , whichever is greater.
Measurement frequency :120Hz at 20°C
Rated voltage (V)
tan
δ
(MAX.)
4
0.37
6.3
0.28
4
6
12
10
0.24
6.3
3
8
16
0.20
10
3
5
25
0.16
16
2
4
25
2
3
35
0.13
35
2
3
50
0.12
50
2
3
Measurement frequency :120Hz
Stability at Low Temperature
Rated voltage (V)
Z– 25°C / Z+20°C
Impedance ratio
ZT / Z20 (MAX.)
Z– 40°C / Z+20°C
Endurance
The specifications listed at right shall be met
when the capacitors are restored to 20°C after
the rated voltage is applied for 2000 hours at
105°C.
Capacitance
change
tan
δ
Leakage current
Within ±25% of the initial capacitance value (16V or less)
Within ±20% of the initial capacitance value (25V or more)
200% or less than the initial specified value
Less than or equal to the initial specified value
Shelf Life
Resistance to soldering
heat
Marking
After storing the capacitors under no load at 105°C for 1000 hours and then performing voltage treatment based on JIS C 5101-4
clause 4.1 at 20°C, they shall meet the specified values for the endurance characteristics listed above.
The capacitors are kept on a hot plate for 30 seconds, which is
Within ±10% of the initial capacitance value
Capacitance change
maintained at 250°C. The capacitors shall meet the characteristic
Less than or equal to the initial specified value
tan
δ
requirements listed at right when they are removed from the plate
Less than or equal to the initial specified value
Leakage current
and restored to 20°C.
Black print on the case top.
Positive
0.5MAX.
0.5MAX.
Plastic platform
Positive
105°C Marking
Chip Type
Voltage
Voltage
φD±0.5
φD±0.5
0.3MAX.
Plastic platform
0.3MAX.
B±0.2
B±0.2
C±0.2
C±0.2
Type numbering system (Example : 16V 10
µ
F)
1
2
3
4
5
6
7
8
9 10 11 12 13 14
Capacitance
105°C Marking
Lot No.
Capacitance
Lot No.
φD
4
A±0.2 E A±0.2
A±0.2 E A±0.2
0.5 to 0.8
0.5 to 0.8
Voltage mark for 6.3V is
Voltage mark for 6.3V is
6V .
6V .
5.8±0.3
5.8±0.3
Negative
Negative
A
φD
1.8
4
B 4.3
A 1.8
C 4.3
B 4.3
E 1.0
C 4.3
E 1.0
(mm)
5 6.3
(mm)
2.1 2.4
5 6.3
5.3 6.6
2.1 2.4
5.3 6.6
5.3 6.6
1.3 2.2
5.3 6.6
1.3 2.2
U
1
U
2
T
3
1
4
C
5
1
6
0
7
0
8
M
9
C L 1
12
G S
10 11
13 14
UU T 1 C 1 0 0 M C L 1 GS
Taping code
A2P
A2P
10 10
16V
16V
Configuration
Taping code
Capacitance tolerance (±20%)
Configuration
Rated capacitance (±20%)
Capacitance tolerance(10µF)
Rated voltage (10µF)
Rated capacitance (16V)
RatedSeries name
voltage (16V)
SeriesType
name
Type
Dimensions
V
Cap.(µF)
Code
1
2.2
3.3
4.7
10
22
33
47
100
4
0G
6.3
0J
10
1A
16
1C
25
1E
35
1V
4
4
4
5
6.3
50
1H
6.2
11
14
19
30
Allowable
ripple
Rated
ripple
010
2R2
3R3
4R7
100
220
330
470
101
4
5
5
6.3
22
30
36
60
4
5
5
6.3
22
30
36
60
5
5
6.3
6.3
27
35
46
60
4
5
6.3
6.3
18
30
40
50
4
5
6.3
6.3
13
23
38
48
4
5
6.3
15
25
42
Case size
φ
D (mm)
Rated ripple current (mArms) at 105°C 120Hz
Frequency coefficient of rated ripple current
Frequency
Coefficient
50 Hz
0.70
120 Hz
1.00
300 Hz
1.17
1 kHz
1.36
10 kHz or more
1.50
Taping specifications are given in page 23.
Recommended land size, soldering by reflow are given in page 18, 19.
Please select UUX(p.156), UUJ(p.162) if high C/V products are required.
Please refer to page 3 for the minimum order quantity.
