FR201G THRU FR207G
GLASS PASSIVATED JUNCTION FAST SWITCHING RECTIFIER
Reverse Voltage -
50 to 1000 Volts
Forward Current -
2.0 Amperes
Features
Plastic package has Underwriters Laboratory
Flammability Classification 94V-0 utilizing
Flame retardant epoxy molding compound
Glass passivated junction in DO-15 package
2.0 ampere operation at T
A
=75 with no thermal runaway
Fast switching for high efficiency
Mechanical Data
Case:
Molded plastic, DO-15
Terminals:
Axial leads, solderable per
MIL-STD-202, method 208
Polarity:
Band denotes cathode
Mounting Position:
Any
Weight:
0.014 ounce, 0.395 gram
DIM ENSIONS
DIM
A
B
C
D
inches
Min.
0.228
0.102
0.028
1.000
Max.
0.299
0.142
0.034
-
Min.
5.8
2.6
0.71
25.40
mm
Max.
7.6
3.6
0.86
-
Note
Maximum Ratings and Electrical Characteristics
Symbols
FR
201G
FR
202G
@25
unless otherwise specified
FR
204G
FR
205G
FR
206G
FR
207G
Units
FR
203G
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Average forward rectified current at T
A
=75
Peak forward surge current 8.3mS single half sine-wave
Maximum instantaneous forward voltage
I
FM
=2.0A; T
A
=25 (Note 1)
Maximum DC reverse current
at rated DC blocking voltage
Maximum reverse recovery time
at I
F
=0.5A, I
R
=1.0A, I
rr
=0.25A
Typical junction capacitance
Measured at 1.0MHz,
V
R
=4.0V
T
A
=25
T
A
=100
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
V
F
I
R
T
rr
C
J
T
J
, T
STG
50
35
50
100
70
100
200
140
200
400
280
400
2.0
70.0
1.3
5.0
100.0
600
420
600
800
560
800
1000
700
1000
Volts
Volts
Volts
Amps
Amps
Volts
A
150
40
-65 to +150
250
500
nS
F
Operating and storage temperature range
Note:
(1) Pulse test: Pulse width 300uSec, Duty cycle 1%
1
