F535L-16: DescriptionStandard Clock Oscillators 16 MHz 3.3Volt 50 ppm -10C +70C; CategoryPassive components; File Size130KB，2 Pages; ManufacturerFOX [Fox Electronics]

Download Datasheet Parametric Compare View All

F535L-16 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	F535L-16	-	-	View	Buy Now

F535L-16 Overview

Standard Clock Oscillators 16 MHz 3.3Volt 50 ppm -10C +70C

F535L-16 Parametric

Parameter Name	Attribute value
Product Category	Standard Clock Oscillators
Manufacturer	FOX [Fox Electronics]
RoHS	Details
Product	Standard Clock Oscillators
Frequency	16 MHz
Frequency Stability	50 PPM
Load Capacitance	15 pF
Operating Supply Voltage	3.3 V
Output Format	HCMOS
Termination Style	SMD/SMT
Minimum Operating Temperature	- 10 C
Maximum Operating Temperature	+ 70 C
Length	5 mm
Width	3.2 mm
Height	1.3 mm
Packaging	Cut Tape
Packaging	MouseReel
Packaging	Reel
Mounting Style	SMD/SMT
Factory Pack Quantity	1000

Preview

Download Datasheet

View All

HcMOS 5x3.2mm 3.3V SMD Oscillator

Model: F530l SERIES

Page 1 of 2

RoHS compliant / Pb Free

Rev. 5/7/2009

http://www.foxonline.com/need_a_sample.htm

FEATuRES

• 3.3V Operation

• Standby Function

• Tape and Reel

(1,000 pcs. STD)

OPTIONS

• 5.0V (F550L) Version Available

• PART NuMbER SElEcTION

Learn More - Internet Required

Part Number

474-Frequency-xxxxx

475-Frequency-xxxxx

476-Frequency-xxxxx

550-Frequency-xxxxx

492-Frequency-xxxxx

636-Frequency-xxxxx

546-Frequency-xxxxx

Model

Number

F530L

F530LR

F535L

F535LR

F536L

F536LR

F538L

Frequency

Operating

Stability

1

Temperature (ºC)

±100PPM

-10 ~ +70

±100PPM

-40 ~ +85

±50PPM

-10 ~ +70

±50PPM

-40 ~ +85

±25PPM

-10 ~ +70

±25PPM*

-40 ~ +85

±20PPM*

-10 ~ +70

Frequency

Range (MHz)

1.544 ~ 155.520

1.544 ~ 77.760

#4

5.0 ± 0.2

#3

Top

View

Dot denotes

pin 1

3.2 ± 0.2

#1

#2

• ElEcTRIcAl cHARAcTERISTIcS

PARAMETERS

Frequency Range (F

O

)

Storage Temperature Range (T

STG

)

Supply Voltage

(V

DD

)

Input Current

(I

DD

)

1.544 ~ 32.000 MHz

32.000+ ~ 50.000 MHz

50.000+ ~ 67.000 MHz

67.000+ ~ 155.520 MHz

Output Symmetry (50% V

DD

)

Rise Time (10% ~ 90% V

DD

) (T

R

)

Fall Time (90% ~ 10% V

DD

) (T

F

)

Output Voltage

(V

OL

)

(V

OH

)

Output Current

(I

OL

)

(I

OH

)

Output Load

(HCMOS)

Standby Current

Start-up Time

(T

S

)

Output Disable Time

2

Output Enable Time

2

Reflow Soldering Temp

Moisture Sensitivity Level (MSL)

Termination Finish

1

1.3 Max

MAX

(unless otherwise noted)

1.544 ~ 155.520 MHz

-55ºC ~ +125ºC

3.3V ± 10%

15mA

20mA

25mA

40mA

40% ~ 60%

7nS

10% V

DD

90% V

DD

Min

2mA Min

-2mA Min

15pF

10µA

10mS

150nS

10mS

260ºC / 10 Seconds

1

Au

Bottom

View

#4

#3

1.0

2.54±0.1

#1

#2

1.2

Recommended

Solder Pad Layout

2.54

1.29

2.25

1.24

Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging,

shock, and vibration. *Excludes Shock/Vibration

2

An internal pullup resistor from pin 1 to pin 4 allows active output if pin 1 is left open.

Note: A 0.01µF bypass capacitor should be placed between V

DD

(Pin 4) and GND (Pin 2) to

minimize power supply line noise.

Drawing is for reference to critical specifications defined by size measurements.

Certain non-critical visual attributes, such as side castellations, reference pin shape, etc. may

vary. All specifications subject to change without notice.

Pin Connections

#1 E/D

#2 GND

#3 Output

#4 V

DD

• ENAblE / DISAblE FuNcTION

INH (Pin 1)

OUTPUT (Pin 3)

2

OPEN

ACTIVE

'1' Level V

IH

≥

70% V

DD

ACTIVE

'0' Level V

IL

≤

30% V

DD

High Z

FOXElectronics

5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554

http://www.foxonline.com
