ALUMINUM ELECTROLYTIC CAPACITORS
LKG
Lug / Snap-in Terminal Type,
For Audio Equipment
Disigned for high grade audio equipment, giving priority to high fidelity sound quality.
The variation expansion of the LKG.
Super Through
TYPE-1: The low profile high tone quality grade of the new development
electrolyte adoption.
TYPE-2: The center grade that the best sound is provided electrode foil,
High Grade
with the multiple use.
TYPE-3: The highest tone quality grade by the low drag the gold plating
Gold Tune
terminal adoption.
The sound quality that it meets the high tone quality needs for HD Audio equipment.
Compliant to the RoHS directive (2011/65/EU).
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
Tangent of loss angle (tan
δ)
–
40 to +85°C
Performance Characteristics
16 to 100V (TYPE-1, TYPE-2, TYPE-3)
680 to 33000µF
± 20% at 120Hz, 20°C
See refer to next page (Measurement frequency : 120Hz at 20°C)
Rated voltage(V)
3
CV
3 CV
After 5 minutes' application of rated voltage at
20°C
, leakage current is not more than
3 CV
(µA),
[C : Rated Capacitance(µF), V : Voltage ( V ) ]
Stability at Low Temperature
Impedance ratio ZT/Z20(MAX.)
Z
–
25°C/ Z+20°C
Z
–
40°C/ Z+20°C
16 to 100
4
12
Measurement frequency : 120Hz
Endurance
The specifications listed at right shall be met when the
capacitors are restored to 20°C after the rated voltage is
applied for 1000 hours at 85°C.
Capacitance change
tan
δ
Leakage current
Within ±20% of the initial capacitance value
200% or less than the initial specified value
Less than or equal to the initial specified value
Shelf Life
Marking
After storing the capacitors under no load at 85°C for 1000 hours and then performing voltage treatment based on JIS C 5101-4 clause
4.1 at 20°C, they shall meet the specified values for the endurance characteristics listed above.
Printed with gold color letter on black sleeve.
Type numbering system (Snap-in terminal type)
(Example : Gold Tune 25 V 6800µF , Dia.φ30)
1
2
3
4
5
6
7
8
9 10 11
12
13 14
Type numbering system (Lug terminal type)
(Example : Super Through 50 V 15000µF)
1
2
3
4
5
6
7
8
9 10 11
12
L KG 1 E 6 8 2 ME S B B K
Grade
Grade
Code
TYPE-1(Gold Tune) AK
TYPE-2(Gold Tune) BK
TYPE-3(Super Through)
CK
Case dia.code
L KG 1 H 1 5 3 MK Z S
Grade
Code
TYPE-1(Gold Tune)
F
—
TYPE-2(Gold Tune)
TYPE-3(Super Through)
S
2
Grade
Configuration
1
Configuration
Capacitance tolerance (±20%)
Rated capacitance(6800
µ
F)
Rated voltage(25V)
Series name
Type
1 Configuration
Pb-free terminal
Pb-free PET sleeve
Capacitance tolerance(±20%)
Rated capacitance(15000
µ
F)
Rated voltage(50V)
Series name
Type
ES
0.8
-0.1
6.3±1
3.5
+0.2
(Snap-in terminal type)
1.5
+0.2
-0.1
0.1
0.8
-
+0
.2
6.3±1
（
1
0
）
Configuration
(Lug terminal type)
P
±1
φ
35 to
φ
40
φ
50 to
φ
76
11±2
Dimension table in next page.
