Molded RF Chokes
Special Features
• High Q, high reliability
• Iron or ferrite core
• Injection molded to protect coil from
extreme environment
• Flame retardant coating
• Consistent body dimension
• Color band or numerical marking identification
• Dielectric strength 1000VRMS
• Operating temperature -55 to +105°C
Part
Number
9210-54
9210-56
9210-58
9210-60
9210-62
9210-64
9210-66
9210-68
9210-70
9210-72
9210-74
9210-76
9210-78
9210-80
9210-82
9210-84
9210-86
9210-88
9210-90
9210-92
9210-94
L (μH)
±5%
36
39
43
47
51
56
62
68
75
82
91
100
110
120
130
150
160
180
200
0
220
240
Q
Min.
60
60
60
55
55
55
55
55
55
50
50
50
60
65
65
65
65
65
65
65
65
9210 Series
Test
SRF
Freq.
(MHz)
(MHz)
Min.
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
0.79
0.79
0.79
0.79
0.7
0.79
.79
0.79
9
0.79
0.79
0.79
15.5
14.5
13.7
13.0
12.7
12.0
11.5
11.0
10.5
10.3
10.0
9.5
8.9
8.7
8.5
8.0
7.5
7.0
6.5
6.2
5.9
DCR
Ω
Max.
2.5
2.6
2.7
2.75
2.85
3.0
3.15
3.3
3.7
3.9
4.3
4.5
4.9
5.2
5.45
6.05
6.40
6.75
7.1
7.45
7.8
I, DC*
(mA)
180
176
172
170
167
164
160
156
147
143
136
133
128
124
121
114
111
108
106
103
101
Notes
* Current to cause 35°C maximum
temperature rise
Also available a RoHS compliant.
vailable as
1.0
Min.
0.375 -/+0.01
0.01
0.025
Dimensions: Inches
0.156 -/+0.01
