Not for New Designs
WVL
www.vishay.com
Vishay Dale
Inductors, Variable, Subminiature, Shielded, Radial Leaded
FEATURES
Classification is grade 3, class A
Subminiature shielded adjustable inductor
High Q values
Vertical or horizontal mounting
Inductance range is 0.10 μH to 1000 μH
0.300" [7.62 mm] diameter by 0.400" [10.16 mm] length
Printed board mounting facilitated by 0.200" [5.08 mm]
grid spacing
• Unit has shield construction to allow maximum density
packaging
• Accommodates close inductance adjustments in high
density circuits that demand exceptional stability and high
“Q” in the smallest size available
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
•
•
•
•
•
•
•
ELECTRICAL SPECIFICATIONS
Adjustable inductance range:
tunable range; ± 5 % for
0.10 μH to 1 μH. ± 10 % for 1.2 μH to 1000 μH
Dielectric strength:
840 V
RMS
at sea level
Working voltage:
300 V
DC
Maximum current:
based on temperature rise not to
exceed 15 °C at +90 °C ambient
Incremental current:
The DC current required to cause a
five percent reduction in the nominal inductance value
Operating temperature:
-55 °C to +105 °C
MECHANICAL SPECIFICATIONS
Tuning tool:
use number WVL-T or equal
Torque:
0.40 inch-ounces to 6 inch-ounces
Terminal pull:
3 pounds
DENSITY SPECIFICATIONS
Weight:
1.5 g maximum
Shielding:
3 % coupling maximum when two units are
tested side by side
DIMENSIONS
in inches [millimeters]
Horizontal Style
0.400 [10.16]
0.320 [8.13]
Vertical Style
0.300 ± 0.020
[7.62 ± 0.508]
3/8 ± 1/16
[9.52 ± 1.59]
0.020
[0.508]
Dia. Wire
Phosphor-Bronze
0.200 ± 0.010
[5.08 ± 0.254]
0.375 [9.53]
0.050 [1.27]
#24 0.020 ± 0.002
[0.508 ± 0.051] TCW
0.200 ± 0.010
[5.08 ± 0.254]
0.400 ± 0.030
[10.16 ± 0.762]
3/8 ± 1/16
[9.52 ± 1.59]
Horizontal Mounting Clip Part Number ACS-57
(One required per unit.)
STANDARD ELECTRICAL SPECIFICATIONS
MODEL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
IND.
(μH)
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
TOL.
Q
(%) TYP.
±5
56
±5
56
±5
56
±5
56
±5
56
±5
64
±5
64
±5
64
±5
64
±5
64
±5
64
±5
68
TEST FREQUENCY
(MHz)
25
25
25
25
25
25
25
25
25
25
25
25
SRF NOM.
(MHz)
200
200
200
200
200
200
200
200
184
176
150
144
DCR MAX.
()
0.030
0.030
0.030
0.035
0.038
0.040
0.040
0.045
0.045
0.050
0.055
0.060
RATED DC CURRENT
(mA)
1510
1450
1400
1370
1340
1300
1260
1240
1200
1160
1100
1040
INCREMENTAL CURRENT
(mA)
-
-
-
-
-
-
-
-
-
-
-
-
Revision: 08-Aug-16
Document Number: 34086
1
For technical questions, contact:
magnetics@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
Not for New Designs
WVL
www.vishay.com
Vishay Dale
SRF NOM.
(MHz)
128
136
124
108
96
83
74
70
63
58
50
48
43
30
23
19
17
16
15
14
12
11
10
9
8.4
4.5
4.0
3.9
3.7
3.4
2.8
2.7
2.6
2.3
2.2
2.0
1.9
DCR MAX.
()
0.070
0.085
0.100
0.110
0.120
0.125
0.165
0.180
0.245
0.265
0.330
0.460
0.640
0.800
0.865
0.940
1.03
1.18
1.30
1.41
1.61
2.08
2.20
2.42
2.15
2.38
2.52
2.88
3.18
3.50
4.80
5.44
5.90
6.30
7.20
8
12
RATED DC CURRENT
(mA)
986
968
893
853
817
800
696
659
571
550
493
417
359
316
301
292
267
243
231
223
203
191
185
174
333
316
306
288
273
260
222
209
201
194
181
172
141
INCREMENTAL CURRENT
(mA)
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
333
190
175
150
125
120
110
105
100
90
80
70
65
STANDARD ELECTRICAL SPECIFICATIONS
MODEL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
WVL
IND. TOL.
Q
(μH) (%) TYP.
1.0
±5
68
1.2
± 10
72
1.5
± 10
80
1.8
± 10
92
2.2
± 10
88
2.7
± 10
88
3.3
± 10
77
3.9
± 10
72
4.7
± 10
76
5.6
± 10
76
6.8
± 10
68
8.2
± 10
76
10
± 10
72
12
± 10
96
15
± 10
96
18
± 10
92
22
± 10 100
27
± 10
92
33
± 10
96
39
± 10
96
47
± 10
88
56
± 10
92
68
± 10
84
82
± 10
84
100 ± 10
76
120 ± 10
76
150 ± 10
72
180 ± 10
76
220 ± 10
76
270 ± 10
80
330 ± 10
80
390 ± 10
80
470 ± 10
80
560 ± 10
76
680 ± 10
80
820 ± 10
72
1000 ± 10
80
TEST FREQUENCY
(MHz)
25
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
MARKING
- Manufacturer data printed
ORDERING INFORMATION - VERTICAL STYLE
WVL
MODEL
0.10 μH
INDUCTANCE VALUE
5%
INDUCTANCE TOLERANCE
EB
PACKAGE CODE
e2
JEDEC
®
LEAD (Pb)-FREE STANDARD
GLOBAL PART NUMBER - VERTICAL STYLE
W
V
L
9
E
B
R
1
0
J
INDUCTANCE TOLERANCE
MODEL
PACKAGE CODE
INDUCTANCE VALUE
ORDERING INFORMATION - HORIZONTAL STYLE
WVL-H
MODEL
0.10 μH
INDUCTANCE VALUE
5%
INDUCTANCE TOLERANCE
EB
PACKAGE CODE
e2
JEDEC
®
LEAD (Pb)-FREE STANDARD
GLOBAL PART NUMBER - HORIZONTAL STYLE
W
V
L
9
E
B
R
1
0
J
INDUCTANCE
TOLERANCE
H
SPECIAL
MODEL
PACKAGE
CODE
INDUCTANCE
VALUE
Revision: 08-Aug-16
Document Number: 34086
2
For technical questions, contact:
magnetics@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
