ERG-2SJ680V

Description
Metal Oxide Resistors Metal Oxide Film Resistor 2W 5%
CategoryPassive components
File Size174KB，8 Pages
ManufacturerPanasonic
Websitehttp://www.panasonic.co.jp/semicon/e-index.html
Download Datasheet Parametric Compare View All

ERG-2SJ680V Online Shopping

Suppliers Part Number Price MOQ In stock
ERG-2SJ680V - - View Buy Now

ERG-2SJ680V Overview

Metal Oxide Resistors Metal Oxide Film Resistor 2W 5%

ERG-2SJ680V Parametric

Parameter NameAttribute value
Product CategoryMetal Oxide Resistors
ManufacturerPanasonic
RoHSDetails
Termination StyleRadial
Resistance68 Ohms
Power Rating2 W
Tolerance5 %
Temperature Coefficient350 PPM / C
Voltage Rating700 V
Operating Temperature Range- 55 C to + 70 C
Diameter4 mm
Length12 mm
QualificationAEC-Q200
Lead Diameter0.8 mm
ProductMetal Oxide Film Resistors
Factory Pack Quantity1000
TypeMetal Oxide Film Resistors Small Size
Unit Weight0.023281 oz

Preview

Download Datasheet
Metal (Oxide) Film Resistors
Metal (Oxide) Film Resistors
Type:
ERG(X)S
(Small size)
(0.5 W, 1 W, 2 W, 3 W, 5 W)
ERG(X)F
(Anti-heat conducting for PCB)
(1 W, 2 W, 3 W, 5 W)
Features
●
Miniaturized
50 % smaller compared to existing models
●
Non-flammable
●
High Reliability
●
Automatic Insertion
●
Reference Standards
IEC 60115-2, IEC 60115-4, JIS C 5201-4, EIAJ RC-2138
●
RoHS compliant
Explanation of Part Numbers
Ex.1 : ERX type
1
2
3
4
5
6
7
8
9
10
11
12
E
R
X
2
S
Z
J
W
1
R
0
E
Product Code
Metal Film
ERX
Resistors
Resistance
Resistance Value
Style · Specification
Tolerance
Small size
The first two digits are significant figures
S
J
±5 %
0.5 W to 5 W
of resistance and the third one denotes
G
±2 %
Small size Anti-heat
number of zeros following.
conducting type
Decimal point is expressed by
F (Fe lead wire)
(Ex.) 1R0 : 1.0
Ω
1 W to 5 W
“Z” is added according to resistance.
The matrix of forming and packaging is as shown in the table below.
Forming & Taping matrix
Resistance
Resistance Value Range (Ω)
Part No. Tolerance
Code
Forming / Packaging
12S 1S 2S 3S 5S 1F 2F 3F 5F
ERX□□SZ
ERX□□S
□···□
Straight lead wire type
±5 %
0.10 to 0.18
0.20 to 9.1
○ ○ ○ ○ ○ ○ ○ ○ ○
ERX12S
□···P
Cut & Forming type
±2 %
0.10 to 0.91
1.0 to 9.1
○ ○ ○ ○ ○
□···V
Axial taping type (Straight lead)
○ ○ ○ ○
ERX1S
±5 %
0.10 to 0.18
0.20 to 9.1
○ ○ ○
U···V Axial taping type (Stand off)
ERX1F
±2 %
0.10 to 0.91
1.0 to 9.1
○ ○ ○
□···E
Radial taping type (E type)
ERX2S
±5 %
0.10 to 0.20
0.22 to 9.1
○ ○ ○
W···E Radial taping type (WE type)
ERX2F
±2 %
0.10 to 0.91
1.0 to 9.1
○ ○ ○ ○
□··H
Cut & Forming type
ERX3S
±5 %
0.10 to 0.20
0.22 to 9.1
○ ○ ○ ○
S···E Radial taping type (SE type)
ERX3F
±2 %
0.10 to 0.91
1.0 to 9.1
○ ○ ○
ERX5S
±5 %
0.33 to 9.1
—
ERX5F
±2 %
1.0 to 9.1
Power Rating at 70 °C
12
0.5 W
1
1W
2
2W
3
3W
5
5W
The above example 1 shows a small metal film resistor, 2 W power rating, resistance value of 1.0
Ω,
tolerance ±5 %, and package of radial taping.
Ex.2 : ERG type
1
2
3
4
5
6
7
8
9
10
11
12
E
R
G
2
S
J
W
1
0
3
E
Product Code
Metal Oxide
ERG
Film Resistors
Power Rating at 70 °C
12
0.5 W
1
1W
2
2W
3
3W
5
5W
Style · Specification
S Small size
0.5 W to 5 W
Small size Anti-heat
conducting type
F
(Fe lead wire)
1 W to 5 W
Resistance
Tolerance
J
±5 %
G
±2 %
Resistance Value
The first two digits are significant figures
of resistance and the third one denotes
number of zeros following.
Decimal point is expressed by
(Ex.) 103 : 10 kΩ
The matrix of forming and packaging is as shown in the table below.
Forming & Taping matrix
Forming / Packaging
Code
12S 1S 2S 3S 5S 1F 2F 3F 5F
□···□
Straight lead wire type
○ ○ ○ ○ ○ ○ ○ ○ ○
□···P
Cut & Forming type
○ ○ ○ ○ ○
□···V
Axial taping type(Straight lead)
○ ○ ○ ○
○ ○ ○
U···V Axial taping type(Stand off)
○ ○ ○
□···E
Radial taping type(E type)
○ ○ ○
W···E Radial taping type(WE type)
○ ○ ○ ○
□···H
Cut & Forming type
○ ○ ○ ○ ○
S···E Radial taping type(SE type)
○ ○ ○
The above example 2 shows a small metal oxide film resistor, 2 W power rating, resistance value of 10 kΩ, tolerance ±5 %, and package of radial taping.
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
02 Sep. 2014

ERG-2SJ680V Related Products

ERG-2SJ680V ERG-2SJ101V ERG-2FJS271E ERG-2FJS511E ERX-2FJSR43E ERG-12SJ911V ERG-3FJS121E
Description Metal Oxide Resistors Metal Oxide Film Resistor 2W 5% Aluminum Electrolytic Capacitors - Leaded 2200uF 35V Metal Oxide Resistors 270ohm 2W 5% Metal Oxide Resistors 2watt 510ohms 5% AEC-Q200 MOSFET N-Ch 1000 Volt 8.3 A Zener SuperMESH Metal Oxide Resistors 91ohm 1/2W 5% Metal Oxide Resistors 3watt 120ohms 5% AEC-Q200
Product Category Metal Oxide Resistors Metal Oxide Resistors Metal Oxide Resistors Metal Oxide Resistors Metal Film Resistors - Through Hole Metal Oxide Resistors Metal Oxide Resistors
Manufacturer Panasonic Panasonic Panasonic Panasonic Panasonic Panasonic Panasonic
RoHS Details Details Details Details Details Details Details
Termination Style Radial Radial Radial Radial Axial Axial Radial
Resistance 68 Ohms 100 Ohms 270 Ohms 510 Ohms 0.43 Ohms 910 Ohms 120 Ohms
Power Rating 2 W 2 W 2 W 2 W 2 W 500 mW (1/2 W) 3 W
Tolerance 5 % 5 % 5 % 5 % 5 % 5 % 5 %
Temperature Coefficient 350 PPM / C 350 PPM / C 350 PPM / C 350 PPM / C 350 PPM / C 350 PPM / C 300 PPM / C
Voltage Rating 700 V 700 V 700 V 700 V 700 V 600 V 700 V
Operating Temperature Range - 55 C to + 70 C - 55 C to + 70 C - 55 C to + 70 C - 55 C to + 70 C - 55 C to + 200 C - 55 C to + 70 C - 55 C to + 70 C
Diameter 4 mm 4 mm 4 mm 4 mm 4 mm 2.3 mm 5.5 mm
Length 12 mm 12 mm 12 mm 12 mm 12 mm 6.35 mm 15 mm
Qualification AEC-Q200 AEC-Q200 AEC-Q200 AEC-Q200 AEC-Q200 AEC-Q200 AEC-Q200
Lead Diameter 0.8 mm 0.8 mm 0.8 mm 0.8 mm 0.8 mm 0.65 mm 0.8 mm
Product Metal Oxide Film Resistors Metal Oxide Film Resistors Metal Oxide Film Resistors Metal Oxide Film Resistors Metal Film Resistors Flameproof Metal Oxide Film Resistors Metal Oxide Film Resistors
Factory Pack Quantity 1000 1000 1000 1000 500 2000 1000
Type Metal Oxide Film Resistors Small Size Metal Oxide Film Resistors Small Size Metal Oxide Film Resistors Anti-Heat Conducting Metal Oxide Film Resistors Anti-Heat Conducting Metal Film Resistors Anit-Heat Conducting Metal Oxide Film Resistors Small Size Metal Oxide Film Resistors Anti-Heat Conducting
Unit Weight 0.023281 oz 0.023281 oz 0.023281 oz 0.023281 oz 0.023281 oz 0.009171 oz 0.051853 oz
