PD-95807 RevB
Half-Bridge FredFet
and Integrated Driver
Description
IR3101
Series
1.6A, 500V
IR3101 is a gate driver IC integrated half bridge FredFET designed for sub 250W (heat-sink-less) motor drive
applications. The sleek and compact single-in-line package is optimized for electronic motor control in
appliance applications such as fans and compressors for refrigerators. The IR3101 offers an extremely
compact, high performance half-bridge inverter, in a single isolated package for a very simple design for two-
phase and three-phase motor drivers.
Proprietary HVIC and latch immune CMOS technologies, along with the HEXFET
®
power FredFET
®
technology (HEXFET
®
with ultra-fast recovery body diode characteristics), enable efficient and rugged
single package construction. Propagation delays for the high and low side power FredFETs are matched
thanks to the advance IC technology.
Features
• Output power FredFets in half-bridge configuration
• High side gate drive designed for bootstrap operation
• Bootstrap diode integrated into package.
• Lower power level-shifting circuit
• Lower di/dt gate drive for better noise immunity
• Excellent latch immunity on all inputs and outputs
• ESD protection on all leads
• Isolation 1500 V
RMS
min
Absolute Maximum Ratings
Absolute maximum ratings indicate sustained limits beyond which damage to the device may occur. All voltage param-
eters are absolute voltages referenced to COM. The thermal resistance and power dissipation are measured under
board mounted and still air conditions.
Parameters Description
V
DD
V
B
P
D
Rth
JC
Rth
JA
V
ISO
T
J
T
S
T
L
I
O
I
O
High voltage supply
High side floating supply
Package power dissipation @ T
C
≤
80 C (per die)
Thermal resistance, junction to case
Thermal resistance, junction to ambient (note 1)
Isolation Voltage (1 min)
Junction temperature (Power Mosfet)
Storage temperature
Lead temperature (soldering, 10 seconds)
Maximum current rating (note 2)
Continuous output current (V
IN
=5V, V
CC
=15V)
(T
C
= 100°C)
(T
C
= 25°C)
o
Max. Values
500
V
o
+ 25
5.8
12
85
1500
-40 to +150
-40 to +150
300
1.6
1.3
2
Units
V
V
W
°C/W
°C/W
V
RMS
°C
°C
°C
A
A
A
Note 1: under normal operational conditions: both power devices working, no heatsink
Note 2: see figure 4, f
PWM
=20kHz
www.irf.com
1
IR3101
Internal Electrical Schematic - IR3101
V
B
8
11
V
DD
V
CC
H
IN
L
IN
V
SS
1
2
3
5
IC Driver
9
V
o
6
COM
Figure 1: Internal connections
Recommended Operating Conditions
For proper operation, the device should be used within the recommended conditions.
Symbol
V
B
V
DD
V
CC
V
IN
V
SS
Definition
High side floating supply absolute voltage
High voltage supply
Low side and logic fixed supply voltage
Logic input voltage
Logic ground
Min.
V
O
+ 10
-
10
V
SS
-5
Max.
V
O
+ 20V
450
20
V
CC
5
Units
V
V
V
V
V
Note 3: Care should be taken to avoid switching condition where the V
O
node flies inductively below COM by more than
5V
2
www.irf.com
IR3101
MOSFET Characteristics
V
BIAS
(V
CC
, V
B
) = 15V and T
A
= 25
o
C unless otherwise specified. The V
DD
parameter is referenced to COM.
Symbol
V
(BR)DSS
I
DSS
R
DS(on)
V
SD
R
DS(on)
V
SD
E
ON
E
OFF
E
REC
t
RR
E
ON
E
OFF
E
REC
t
RR
C
oss
Definition
Drain-to-Source breakdown
voltage
Drain-to-Source leakage
current
Static drain-to-source on
resistance
Diode forward voltage
Static drain-to-source on
resistance
Diode forward voltage
Turn-On energy losses
Turn-Off energy losses
Body-Diode reverse recovery
Llosses
Reverse recovery time
Turn-On energy losses
Turn-Off energy losses
Body-Diode reverse recovery
Llosses
Reverse recovery time
Output capacitance
Min.
500
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Typ
-
-
0.8
0.82
1.7
0.70
100
5
10
105
150
10
15
130
-
Max.
-
50
1.0
0.9
2.0
0.79
135
10
20
180
205
17
35
230
100
Units
V
Conditions
V
IN
=0V, I
D
=250µA
V
DS
=500V, V
IN
=0V
I
D
= 1.5A
I
D
= 1.5A, V
IN
=0V
I
D
= 1.5A, T
J
=125°C
I
D
= 1.5A, V
IN
=0V, T
J
=125°C
I
F
= 1.5A
V
CC
= 300V
di/dt = 200A/µs
µ
A
Ω
V
Ω
V
µJ
µJ
µJ
ns
µJ
µJ
µJ
ns
pF
T
J
=125°C
I
F
= 1.5A
V
CC
= 300V
di/dt = 200A/µs
V
IN
=0V, V
DD
=30V, f=1MHz
www.irf.com
3
IR3101
Driver IC Characteristic
Symbol
V
CCUV+
V
CCUV-
V
CCUVH
V
BSUV+
V
BSUV-
V
BSUVH
V
IH
V
IL
I
IN+
I
IN-
MT
Definition
V
CC
supply undervoltage
positive going threshold
V
CC
supply undervoltage
negative going threshold
V
CC
supply undervoltage
lockout hysteresis
V
BS
supply undervoltage
positive going threshold
V
BS
supply undervoltage
negative going threshold
V
BS
supply undervoltage
lockout hysteresis
Logic "1" input voltage for HIN
& LIN
Logic "0" input voltage for HIN
& LIN
Logic "1" input bias current
Logic "0" input bias current
Delay Matching HS & LS turn
on/ turn off
Min.
8.0
7.4
0.3
8.0
7.4
0.3
2.9
-
-
-
-
Typ.
8.9
8.2
0.7
8.9
8.2
0.7
-
-
5
1
0
Max.
9.8
9.0
-
9.8
9.0
-
-
0.8
20
2
30
Units
V
V
V
V
V
V
V
V
V
CC
=10V to 20V
V
CC
=10V to 20V
H
IN
, L
IN
= 5V
H
IN
, L
IN
= 0V
Conditions
µ
A
µ
A
ns
V
B
8
11
V
DD
H
IN
0
1
L
IN
1
0
1
X
V
O
0
V
DD
Shoot-Through
condition
X
V
CC
H
IN
L
IN
V
SS
1
2
3
5
IC Driver
9
V
o
1
X
6
COM
Figure 2: Driver input/output relation
4
www.irf.com
IR3101
Module Pin-Out Description
Pin
1
2
3
4
5
6
7
8
9
10
11
V
DD
V
B
V
O
V
SS
COM
Symbol
V
CC
H
IN
L
IN
Lead Definitions
Logic and internal gate drive supply
Logic input for high side gate output
Logic input for low side gate output
Not Connected
Logic Ground
Low side MOSFET gate return
Not Connected
High side gate drive floating supply
Half bridge output
Not Connected
High voltage supply
www.irf.com
5
