Part Number

Search

MAX1188ACUP-

Description
Analog to Digital Converters - ADC 16-Bit 135ksps 4.2V Precision ADC
Categorysemiconductor    Analog mixed-signal IC
File Size327KB,14 Pages
ManufacturerMaxim
Websitehttps://www.maximintegrated.com/en.html
Download Datasheet Parametric Compare View All

MAX1188ACUP- Online Shopping

Suppliers Part Number Price MOQ In stock
MAX1188ACUP- - - View Buy Now

MAX1188ACUP- Overview

Analog to Digital Converters - ADC 16-Bit 135ksps 4.2V Precision ADC

MAX1188ACUP- Parametric

Parameter NameAttribute value
Product CategoryAnalog to Digital Converters - ADC
ManufacturerMaxim
RoHSDetails
Mounting StyleSMD/SMT
Package / CaseTSSOP-20
Resolution16 bit
Number of Channels1 Channel
Sampling Rate135 kS/s
Input TypeSingle-Ended
Interface TypeParallel
ArchitectureSAR
Reference TypeExternal, Internal
SNR - Signal to Noise Ratio91 dB
Maximum Operating Temperature+ 70 C
Minimum Operating Temperature0 C
PackagingTube
DNL - Differential Nonlinearity+/- 1 LSB
Height0.9 mm
INL - Integral Nonlinearity+/- 2 LSB
Length6.5 mm
Number of Converters1 Converter
Operating Supply Voltage2.7 V to 5.25 V, 4.75 V to 5.25 V
Pd - Power Dissipation879 mW
ProductAnalog to Digital Converters
Reference Voltage4.096 V
Factory Pack Quantity74
Width4.4 mm
Unit Weight0.006737 oz
19-2755; Rev 1; 8/03
16-Bit, 135ksps, Single-Supply ADCs with
Bipolar Analog Input Range
General Description
The MAX1178/MAX1188 16-bit, low-power, successive-
approximation analog-to-digital converters (ADCs) fea-
ture automatic power-down, a factory-trimmed internal
clock, and a byte-wide parallel interface. The devices
operate from a single +4.75V to +5.25V analog supply
and feature a separate digital supply input for direct
interface with a +2.7V to +5.25V digital logic.
The MAX1188 accepts a bipolar analog input voltage
range of ±10V, while the MAX1178 accepts a bipolar
analog input voltage range of ±5V. All devices consume
no more than 26.5mW at a sampling rate of 135ksps
when using an external reference, and 31mW when using
the internal +4.096V reference. AutoShutdown™ reduces
supply current to 0.4mA at 10ksps.
The MAX1178/MAX1188 are ideal for high-perfor-
mance, battery-powered, data-acquisition applications.
Excellent AC performance (THD = -100dB) and DC
accuracy (±2 LSB INL) make the MAX1178/MAX1188
ideal for industrial process control, instrumentation, and
medical applications.
The MAX1178/MAX1188 are available in a 20-pin
TSSOP package and are fully specified over the -40°C
to +85°C extended temperature range and the 0°C to
+70°C commercial temperature range.
o
Byte-Wide Parallel Interface
o
Analog Input Voltage Range: ±10V, ±5V
o
Single +4.75V to +5.25V Analog Supply Voltage
o
Interface with +2.7V to +5.25V Digital Logic
o
±2 LSB INL
o
±1 LSB DNL
o
Low Supply Current (max)
2.9mA (External Reference)
3.8mA (Internal Reference)
5µA AutoShutdown Mode
o
Small Footprint
o
20-Pin TSSOP Package
Features
MAX1178/MAX1188
Ordering Information
PART
MAX1178ACUP
MAX1178BCUP
MAX1178CCUP
MAX1178AEUP
MAX1178BEUP
MAX1178CEUP
TEMP RANGE
0°C to +70°C
0°C to +70°C
0°C to +70°C
-40°C to +85°C
-40°C to +85°C
-40°C to +85°C
INPUT
PIN-
VOLTAGE
PACKAGE
RANGE (V)
20 TSSOP
20 TSSOP
20 TSSOP
20 TSSOP
20 TSSOP
20 TSSOP
±5
±5
±5
±5
±5
±5
Ordering Information continued at end of data sheet.
Applications
Temperature Sensing and Monitoring
Industrial Process Control
I/O Modules
Data-Acquisition Systems
Precision Instrumentation
ANALOG INPUT
Typical Operating Circuit
+5V ANALOG +5V DIGITAL
0.1µF
0.1µF
AV
DD
AIN
DV
DD
µP
DATA
D0–D7 BUS
OR
D8–D15
EOC
REF
REFADJ
MAX1178
MAX1188
R/C
CS
HBEN
Pin Configuration and Functional Diagram appear at end of
data sheet.
AutoShutdown is a trademark of Maxim Integrated Products, Inc.
HIGH
BYTE
LOW
BYTE
AGND DGND
0.1µF
10µF
________________________________________________________________
Maxim Integrated Products
1
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim’s website at www.maxim-ic.com.
