DUAL-IN-LINE
SOCKETS
SERIES 146 • SOLDERLESS PRESS
-
FIT, COMPLIANT TAIL • OPEN FRAME
.015-.025
.010 .018
B
•
Unique compliant tail pins conform to a
.040”+ .003” nished plated through hole
diameter without stressing inner layers
and .090”-.130” thick panels
.195
.150
.101
.110
.173
L=.120
OR
L=.175
•
Two tails lengths are o ered for .060”-.100”
•
Series 146 uses MM #4612 or MM #4613 pins
with a BeCu #30 contact, rated at 3 amps.
See page 162 for details
.060-.100
OR
.090-.130
.037-.043
DIA. HOLE
.018
SLOT
.045 DIA.
.035 DIA.
•
Insulators are high temperature thermoplastic
•
For Electrical, Mechanical and Environmental
Data, see page 264 for details
See page 130 for Insulator Details
APPLICATION OF COMPLIANT TAIL PINS
Mill-Max’s patented
*
precision-machined pins feature compliant tails that are hollow and
slotted to conform to a .040” ± .003” diameter PTH. As the pin is inserted, the slot compresses
to t the PTH, thus avoiding damage (see illustration at left). The pin’s tail has ne serrations
that form a perfect “gas tight” connection that doesn’t require soldering. And since the pin
doesn’t damage the hole, compliant tail sockets and connectors can be easily replaced.
*
Patent No. 4,799,904.
Total number
of pins
A
B
.100
C
Quantity
per tube
ORDERING INFORMATION
(for .060”-.100” thick panel)
146-XX-306-41-012000
146-XX-308-41-012000
146-XX-314-41-012000
146-XX-316-41-012000
146-XX-318-41-012000
146-XX-320-41-012000
146-XX-324-41-012000
146-XX-422-41-012000
146-XX-624-41-012000
146-XX-628-41-012000
146-XX-632-41-012000
146-XX-640-41-012000
A
0.3
0.4
0.7
0.8
0.9
1.0
1.2
1.1
1.2
1.4
1.6
2.0
B
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.4
0.6
0.6
0.6
0.6
C
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.5
0.7
0.7
0.7
0.7
L = .120
(for .090”-.130” thick panel)
146-XX-306-41-013000
146-XX-308-41-013000
146-XX-314-41-013000
146-XX-316-41-013000
146-XX-318-41-013000
146-XX-320-41-013000
146-XX-324-41-013000
146-XX-422-41-013000
146-XX-624-41-013000
146-XX-628-41-013000
146-XX-632-41-013000
146-XX-640-41-013000
2011/65/EU
L = .175
22
24
28
32
40
18
16
14
12
10
RoHS - 2
XX=Plating Code
See Below
41
43
200
µ”
Sn
30
µ”
Au
SPECIFY PLATING CODE XX =
Sleeve (Pin)
Contact (Clip)
91
200
µ”
Sn/Pb
10
µ”
Au
93
200
µ”
Sn/Pb
30
µ”
Au
200
µ”
Sn
10
µ”
Au
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
PAGE 97 | IC SOCKETS / TO SOCKETS
