LESHAN RADIO COMPANY, LTD.
35A BRIDGE RECTIFIERS
35A
35A BRIDGE RECTIFIERS
Absolute MAX rating
Description
Storage Temperature
Operating Junction
Temperature
MAX reverse Voltage
MP351
MP352
MP354
MP356
MP358
MP3510
Average rectifled
Forward Current
Surge Current
Dielectric strength
Symbols
Conditions
Ratings
–55 ~ +175
Unit
T
STG
T
J
V
RM
°C
°C
150
100
200
400
600
800
1000
V
I
O
I
FSM
Vdia
50Hz Sine wave resistance load T
C
=55°C
50Hz
Non-repetitive 50Hz 10ms Sine wave
T
J
= 25°C
50Hz 10ms
35
300
2
A
A
Terminals to case AC 1 minute
AC1
KV
Electrical characteristics Ta = 25°C
Forward Voltage
Reverse leakage current
Thermal resistance
32
9
V
F
I
R
Q
JC
I
F
= 17.5A
V
R
= V
RM
Junction to Case
25
Max1.05
Max 10
Max 1.5
V
µA
°C / W
11
7.2
18
6.35
32
φ
2.4
0.8
14.4
φ
4.9
Fsston tab # 250 eq.
Outline dimensions
16C–1/2
LESHAN RADIO COMPANY, LTD.
MP351-MP3510
35A
35A BRIDGE RECTIFIERS RATING & CHARACTERISTIC CURVES
FIG. 1 - DERATING CURVE FOR OUTPUT
RECTIFIED CURRRENT
FIG. 2 - MAXIMUM NON-REPETITIVE PEAK FORWARD
SURGE CURRENT PER BRIDGE ELEMENT
AVERAGE FORWARD OUTPUT CURRENT AMPERES
AVERAGE OUTPUT CURRENT.AMPERES
300
35
250
20
200
15
100
10
50
5
1Cycie
T
J
= 150°C
Single Sine-Wave
0
0
80
160
0
0
1
10
100
AMBIENT TEMPERATUER.°C
NUMBER OF CYCLES AT 50Hz
FIG. 3 - TYPICAL FORWARD CHARACTERISTICS
PER BRIDGE ELEMENT
100
FIG. 4 - TYPICAL REVERSE CHARACTERISTICS
PER BRIDGE ELEMENT
100
INSTANTANEOUS REVERSE CURRENT
MICRO AMPERES(µA)
INSTANTANEOUS FORWARD
CURRENT AMPERES
10
10
T
J
= 125°C
1.0
1.0
0.1
T
J
= 25°C
0
0.4
0.6
0.8
1.0
1.2
1.4
1.6
0.01
20
40
60
80
100
120
140
FORWARD VOLTAGE.VOLTS
PERCENT OF RATED PEAK REVERSE VOLTAGE %
16C–2/2
