MOCD213

Description
DUAL CHANNEL SMALL OUTLINE OPTOISOLATOR TRANSISTOR OUTPUT
CategoryLED optoelectronic/LED    photoelectric
File Size61KB,4 Pages
ManufacturerMotorola ( NXP )
Websitehttps://www.nxp.com
Download Datasheet Parametric View All

MOCD213 Online Shopping

Suppliers Part Number Price MOQ In stock
MOCD213 - - View Buy Now

MOCD213 Overview

DUAL CHANNEL SMALL OUTLINE OPTOISOLATOR TRANSISTOR OUTPUT

MOCD213 Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerMotorola ( NXP )
package instructionPLASTIC, SOIC-8
Reach Compliance Codeunknow
Coll-Emtr Bkdn Voltage-Mi70 V
ConfigurationSEPARATE, 2 CHANNELS
Nominal current transfer ratio100%
Maximum dark power50 nA
Maximum forward current0.06 A
Maximum insulation voltage3000 V
JESD-609 codee0
Number of components2
Maximum operating temperature100 °C
Minimum operating temperature-55 °C
Optoelectronic device typesTRANSISTOR OUTPUT OPTOCOUPLER
Terminal surfaceTin/Lead (Sn/Pb)
MOTOROLA
SEMICONDUCTOR TECHNICAL DATA
Order this document
by MOCD213/D
Dual Channel
Small Outline Optoisolator
Transistor Output
This device consists of two gallium arsenide infrared emitting diodes optically
coupled to two monolithic silicon phototransistor detectors, in a surface
mountable, small outline, plastic package. It is ideally suited for high density
applications and eliminates the need for through–the–board mounting.
Dual Channel Coupler
Convenient Plastic SOIC–8 Surface Mountable Package Style
Minimum Current Transfer Ratio 100% with Input Current of 10 mA
Minimum V(BR)CEO of 70 Volts Guaranteed
Standard SOIC–8 Footprint, with 0.050″ Lead Spacing
Shipped in Tape and Reel, which Conforms to EIA Standard RS481A
Compatible with Dual Wave, Vapor Phase and IR Reflow Soldering
High Input–Output Isolation of 3000 Vac (rms) Guaranteed
Meets U.L. Regulatory Requirements, File #E54915
Ordering Information:
To obtain MOCD213 in tape and reel, add R2 suffix to device number as follows:
R2 = 2500 units on 13″ reel
To obtain MOCD213 in quantities of 50 (shipped in sleeves) — no suffix
Marking Information:
MOCD213 = D213
Applications:
Feedback Control Circuits
Interfacing and Coupling Systems of Different Potentials and Impedances
General Purpose Switching Circuits
Monitor and Detection Circuits
MAXIMUM RATINGS
(TA = 25°C unless otherwise noted)
Rating
INPUT LED
Forward Current — Continuous
Forward Current — Peak (PW = 100
µs,
120 pps)
Reverse Voltage
LED Power Dissipation @ TA = 25°C
Derate above 25°C
OUTPUT TRANSISTOR
Collector–Emitter Voltage
Collector–Base Voltage
Emitter–Collector Voltage
Collector Current — Continuous
Detector Power Dissipation @ TA = 25°C
Derate above 25°C
VCEO
VCBO
VECO
IC
PD
70
70
7.0
150
150
1.76
V
V
V
mA
mW
mW/°C
IF
IF(pk)
VR
PD
60
1.0
6.0
90
0.8
mA
A
V
mW
mW/°C
Symbol
Value
Unit
MOCD213
[CTR = 100% Min]
DUAL CHANNEL
SMALL OUTLINE
OPTOISOLATOR
TRANSISTOR OUTPUT
CASE 846–01, STYLE 3
PLASTIC
SCHEMATIC
1
2
3
4
8
7
6
5
1.
2.
3.
4.
5.
6.
7.
8.
ANODE 1
CATHODE 1
ANODE 2
CATHODE 2
EMITTER 2
COLLECTOR 2
EMITTER 1
COLLECTOR 1
NOTE: Thickness through insulation between input and output is
0.5 mm.
REV 2
©
Motorola
Inc. 1995
Motorola,
Optoelectronics Device Data
1
