39-30-4038 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 39-30-4038

39-30-4038: DescriptionHeaders u0026 Wire Housings MiniFit Jr. 3Ckt Rec ecept. Hsg V-2 Black; CategoryThe connector The connector; File Size30KB，2 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home; Environmental Compliance

Download Datasheet Parametric View All

39-30-4038 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	39-30-4038	-	-	View	Buy Now

39-30-4038 Overview

Headers u0026 Wire Housings MiniFit Jr. 3Ckt Rec ecept. Hsg V-2 Black

39-30-4038 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	LEAD FREE
Reach Compliance Code	compliant
Other features	MINI-FIT JR
Connector type	RECTANGULAR POWER CONNECTOR
Contact to complete cooperation	GOLD (30)
Contact completed and terminated	TIN (100)
Contact point gender	MALE
Contact material	BRASS
DIN compliance	NO
empty shell	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e3
MIL compliance	NO
Manufacturer's serial number	5569
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation type	CABLE
Options	GENERAL PURPOSE
Shell material	POLYAMIDE66
Termination type	SOLDER
Total number of contacts	3
UL Flammability Code	94V-0
Base Number Matches	1

Preview

Download Datasheet

View All

This document was generated on 03/02/2012

PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

Part Number:

Status:

Overview:

Description:

0039304038

Active

minifit_jr

4.20mm Pitch Mini-Fit Jr.™ Header, Single Row, Right Angle, with PCB Mounting

Flanges, 3 Circuits, PA Polyamide Nylon 6/6, 94V-0, 0.76µm Gold (Au)

Documents:

3D Model

Drawing (PDF)

Product Specification PS-5556-001 (PDF)

Packaging Specification PK-5569-002 (PDF)

Test Summary TS-5556-002 (PDF)

RoHS Certificate of Compliance (PDF)

image - Reference only

Series

Agency Certification

CSA

TUV

LR19980

R72081037

E29179

EU RoHS

ELV and RoHS

Compliant

REACH SVHC

Contains SVHC: No

Low-Halogen Status

Low-Halogen

China RoHS

General

Product Family

Series

Application

Comments

PCB Headers

5569

Power, Wire-to-Board

Current = 13A max. per circuit when header is mated

to a receptacle loaded with 45750 Mini-Fit® Plus HCS

Crimp Terminal Crimped to 16 AWG wire., See Molex

Product specification PS-5556001 for additional current

de-rating information.

minifit_jr

Mini-Fit Jr.™

Need more information on product

environmental compliance?

Email productcompliance@molex.com

For a multiple part number RoHS Certificate of

Compliance, click here

Please visit the Contact Us section for any

non-product compliance questions.

Overview

Product Name

Physical

Breakaway

Circuits (Loaded)

Circuits (maximum)

Color - Resin

Durability (mating cycles max)

First Mate / Last Break

Flammability

Glow-Wire Compliant

Guide to Mating Part

Keying to Mating Part

Lock to Mating Part

Material - Metal

Material - Plating Mating

Material - Plating Termination

Material - Resin

Number of Rows

Orientation

PCB Locator

PCB Retention

PCB Thickness - Recommended

Packaging Type

Pitch - Mating Interface

Pitch - Termination Interface

Plating min - Mating

Plating min - Termination

Polarized to Mating Part

Polarized to PCB

Natural

94V-0

None

Yes

Brass

Gold

Tin

Nylon

Right Angle

Yes

1.78mm

Bag

4.20mm

0.762µm

2.540µm

Yes

Search Parts in this Series

5569Series

Mates With

39014031 Receptacle
