SPECIFICATIONS
Rated:
Contact Material:
Screw Material:
Housing Material:
Insulation Resistance:
Terminal Material:
Screw Torque:
Wire Range:
Withstanding:
Operating Temp:
12 Amps
Phosphor Bronze, Nickel Plated
Steel, M2.6 Nickel Plated
Polyamide 66 UL94V-0, Green
1000MΩmin
Brass, Tin Plated
7 In-Lb
12~16 AWG
AC200V min
-55ºC ~ +115ºC
A
B
C
D
E
F
RoHS compliant
Rev.
Description
Date
Approved
Drawing
Name
Approved Howard
Checked Lizzy
Drawn Tina
0.0 ± 0.35
1
2
3
4
Series
Type
Pitch
Positions
CMTB
HD515MT
XXX
XX
Terminal block Wire mount type 500=5.00mm
2-24
508=5.08mm (.200”)
Date
08/10/99
08/10/99
08/10/99 Part No.:
Color
XX
GN=Green
F
Central Components Manufacturing
440 Lincoln Blvd., Middlesex, New Jersey 08846
Phone 732 469-5720 888 288-5152 Fax 732 469-1919
CMTB-HD515MT-500-XX-GN
G
7
8
9
G
0.00 ± 0.20 Angles ± 3’
UNIT: mm
5
6
Description: Wire Mount Type Terminal Block
