Fixed PCB Blocks
Pin Spacing:
Orientation:
Clamp Type:
Design:
5.00mm
Horizontal
Tubular Screw with
Wire Protector
Modular
Pin Spacing:
Orientation:
Clamp Type:
Design:
5.00mm
Horizontal
Screw Cage
Modular
MHE-16
ELECTRICAL
Current
16A
Voltage
250V
Wire Range
22-14AWG
ELECTRICAL
Current
10A
13.5A
Voltage
300V
250V
MH-15
Wire Range
30-16AWG
1.5mm
2
Stranded
2.5mm
2
Solid
INSTALLATION
DATA
Screw Size
M3
Torque
0.5Nm
(4.5 lbf-in.)
MATERIAL
Body
Glass-Filled Polyester
Flammability Class
UL94V-0
Temperature Limit
130˚C UL
125˚C IEC
Color
Black
No. Poles
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
B
M
A
H
Cat. #
MHE-162
MHE-163
MHE-164
MHE-165
MHE-166
MHE-167
MHE-168
MHE-169
MHE-1610
MHE-1611
MHE-1612
MHE-1613
MHE-1614
MHE-1615
MHE-1616
MHE-1617
MHE-1618
MHE-1619
MHE-1620
MHE-1621
MHE-1622
MHE-1623
MHE-1624
PCB Hole Size
1.3mm
Stripping Lgth.
5.8mm
INSTALLATION
DATA
Screw Size
M3
Torque
0.5Nm
(4.5 lbf-in.)
MATERIAL
Body
PA6.8
Flammability Class
UL94V-0
Temperature Limit
105˚C UL
125˚C IEC
Color
Green
No. Poles
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
B
I
PCB Hole Size
1.3mm
Stripping Lgth.
6.7mm
Screw
Galvanized Steel
Terminal
Tin-Plated Brass
Wire Protector
CuSn6
Screw
Terminal
Clamp
Galvanized Steel
Tin-Plated Brass
Nickeled Brass
Length (B) (mm)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
105.0
110.0
115.0
120.0
P
P/2
Std. Pk.
100
100
50
50
50
50
50
50
50
50
50
20
20
20
20
20
20
20
20
20
20
20
20
Cat. #
MH-152
MH-153
MH-154
MH-155
MH-156
MH-157
MH-158
MH-159
MH-1510
MH-1511
MH-1512
MH-1513
MH-1514
MH-1515
MH-1516
MH-1517
MH-1518
MH-1519
MH-1520
MH-1521
MH-1522
MH-1523
MH-1524
0.6
Length (B) (mm)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
75.0
80.0
85.0
90.0
95.0
100.0
105.0
110.0
115.0
120.0
C
K
Std. Pk.
100
100
50
50
50
50
50
50
50
50
50
20
20
20
20
20
20
20
20
20
20
20
20
O
J
C
K
Dimensions
A
B
C
D
E
F
G
H
12.50 mm
10.00 mm
9.00 mm
3.40 mm
–
–
4.50 mm
8.80 mm
I
J
K
L
M
N
O
P
–
Ø3.10 mm
Ø3.95 mm
–
Ø1.00 mm
–
2.00 mm
5.00 mm
A
J
M
P/2
P
P/2
D
O L
H
G
Dimensions
A
B
C
D
E
F
G
H
10.60 mm
10.00 mm
8.50 mm
3.70 mm
–
–
1.50 mm
4.40 mm
I
J
K
L
M
N
O
P
2.60 mm
1.70 mm
Ø3.90 mm
0.50 mm
0.90 mm
–
1.80 mm
5.00 mm
D
G
Altech Corp.
®
• 35 Royal Road • Flemington, NJ 08822-6000 • Phone (908)806-9400 • FAX (908)806-9490 • www.altechcorp.com
