PM3316-221M-RC datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> inductor> PM3316-221M-RC

PM3316-221M-RC: DescriptionThick Film Resistors - SMD ZERO OHM JUMPER; CategoryPassive components inductor; File Size342KB，2 Pages; ManufacturerBourns; Websitehttp://www.bourns.com; Environmental Compliance

Download Datasheet Parametric Compare View All

PM3316-221M-RC Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	PM3316-221M-RC	-	-	View	Buy Now

PM3316-221M-RC Overview

Thick Film Resistors - SMD ZERO OHM JUMPER

PM3316-221M-RC Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	5039
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	12 weeks
uppercase and lowercase codes	5039
structure	Unshielded
core material	FERRITE
DC Resistance	0.78 Ω
Nominal inductance(L)	220 µH
Inductor Applications	POWER INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
JESD-609 code	e3
Number of functions	1
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
Package height	5 mm
Package length	12.7 mm
Package form	SMT
Package width	10 mm
method of packing	TR, 13 Inch
Minimum quality factor (at nominal inductance)	33
Maximum rated current	0.8 A
self resonant frequency	5 MHz
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
surface mount	YES
Terminal surface	Tin (Sn) - with Nickel (Ni) barrier
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Test frequency	0.001 MHz
Tolerance	20%
Base Number Matches	1

Preview

Download Datasheet

View All

Features

■

Formerly

■

Available in E6 series

■

Low proﬁle of only 5.0 mm

■

Inductance as low as 1.0 µH

■

RoHS compliant*

Applications

model

■

Input/output of DC/DC converters

■

Power supplies for:

•

Portable communication equipment

Camcorders

LCD TVs

Car radios

PM3316 Series - SMD Power Inductors

Electrical Speciﬁcations

Inductance 1 kHz

General Speciﬁcations

Test

Q Frequency

Ref.

(MHz)

0.05

0.07

SRF

Min.

(MHz)

137

I rms

Max.

(A)

7.50

6.50

6.10

5.00

4.50

3.40

2.90

2.50

2.00

1.80

1.40

1.20

1.00

0.80

0.70

0.55

0.45

0.35

0.30

I sat

Typ.

(A)

9.00

8.00

7.00

6.40

5.40

4.50

3.70

3.00

2.50

2.00

1.60

1.40

1.20

1.00

0.80

0.60

0.50

0.40

0.35

Bourns Part No.

PM3316-1R0M-RC

PM3316-1R5M-RC

PM3316-2R2M-RC

PM3316-3R3M-RC

PM3316-4R7M-RC

PM3316-6R8M-RC

PM3316-100M-RC

PM3316-150M-RC

PM3316-220M-RC

PM3316-330M-RC

PM3316-470M-RC

PM3316-680M-RC

PM3316-101M-RC

PM3316-151M-RC

PM3316-221M-RC

PM3316-331M-RC

PM3316-471M-RC

PM3316-681M-RC

PM3316-102M-RC

(µH)

1.5

2.2

3.3

4.7

6.8

100

150

220

330

470

680

1000

Tol. %

± 20

RDC

(Ω)

0.007

0.009

0.012

0.015

0.019

0.030

0.050

0.060

0.10

0.12

0.19

0.24

0.33

0.59

0.78

1.15

1.70

2.60

3.90

Test Voltage ....................................0.1 V

Reﬂow soldering .... 250 °C; 10 sec max.

(In compliance with JEDEC,

J-STD-020C, Table 4-2)

Operating Temperature

................................-55 °C to +125 °C

(Temperature rise included)

Storage Temperature

................................-55 °C to +125 °C

Resistance to Soldering Heat

.......................... 250 °C, 10 sec. max.

Materials

Core ....................................... Ferrite DR

Wire ............................Enameled copper

Base ................................................DAP

Terminal ........................................Cu/Sn

Rated Current

...................Ind. drop 10 % typ. at Isat

Temperature Rise ................. 15 °C max.

at rated Irms

Packaging .................... 500 pcs. per reel

Product Dimensions

101

Electrical Schematic

10.0

0.2

(.393

.008)

12.7

0.2

(.500

.008)

5.0

0.3

MAX.

(.197

.012)

7.6

0.3

TYP.

(.299

.012)

2.4

0.2

TYP.

(.094

.008)

2.5

0.2

TYP.

(.098

.008)

• = START OF WINDING

Recommended Layout

7.3

(.287)

2.8

(.110)

3.0

(.118)

*RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.

Speciﬁcations are subject to change without notice.

Customers should verify actual device performance in their speciﬁc applications..

DIMENSIONS:

(INCHES)
