PDxxxR
SMT Power Choke Core
** Test Measurement Frequency
Values < 10µH tested @ 7.96 MHz;
Values
≥10uH
tested @ 1.0 kHz
Mechanical Configuration
Units designed for Surface Mounting
Terminals
Solder Coated
Core Construction
High Resistivity Ferrite
Operating Temperature Range
–55°C to +125°C
Current Rating at 25°C Ambient
The maximum DC Current that will cause a
40°C maximum temperature rise and where the inductance will not decrease
by more than 10% from the zero DC value.
Inductance Tolerance
Tolerance is indicated by the suffix to API part number.
Standard tolerance per part number is as shown in table.
M = ±20%; K = ±10%.
Marking
For values lower than 10 H the R indicates a decimal point and the
remaining digits indicate the inductance in H. For values 10 H and above, the
first two digits indicate the inductance in H and the third digit indicates the
number of trailing zeros where a zero indicates that there are no trailing zeros.
Actual Size (PD105R)
Example: PD43R-102M (1.0 H)
1R0
Example: PD73R-224K (220 H)
221
Physical Parameters
Dimensions
Inches
PD43R
0.165 ±0.024
A
0.137 MAX.
B
0.153 ±0.012
C
0.060 REF.
D
Millimeters
A
B
C
D
PD43R
PD54R
PD73R
PD75R
PD104R
PD105R
0.224 ±0.008
0.177 MAX.
0.201 ±0.008
0.051 REF.
PD54R
0.303 ±0.008
0.138 MAX.
0.272 ±0.008
0.063 REF.
PD73R
0.303 ±0.008
0.197 MAX.
0.272 ±0.008
0.063 REF.
PD75R
0.386 ±0.016
0.157 MAX.
0.346 ±0.016
0.083 REF.
PD104R
0.386 ±0.016
0.213 MAX.
0.346 ±0.016
0.083 REF.
PD105R
4.2 ±0.6
3.5 MAX.
3.9 ±0.3
1.52 REF.
5.7 ±0.2
4.5 MAX.
5.1 ±0.2
1.30 REF.
7.7 ±0.2
3.5 MAX.
6.9 ±0.2
1.60 REF.
7.7 ±0.2
5.0 MAX.
6.9 ±0.2
1.60 REF.
9.8 ±0.4
4.0 MAX.
8.8 ±0.4
2.10 REF.
9.8 ±0.4
5.4 MAX.
8.8 ±0.4
2.10 REF.
Packaging
Tape & reel: 7" reel not available; maximum pieces per 13" reel as follows
PD43R
PD54R
PD73R
PD75R
mm
12
16
16
16
Pieces
1500
1000
1000
500
PD104R
24
1000
PD105R
24
500
**Additional Information on Next Page
