MMZ1005Y301CT

Description
1 FUNCTIONS, 0.25 A, FERRITE CHIP
CategoryAnalog mixed-signal IC    filter
File Size75KB,4 Pages
ManufacturerTDK Corporation
Websitehttp://www.tdk.com
Environmental Compliance
Download Datasheet Parametric View All

MMZ1005Y301CT Overview

1 FUNCTIONS, 0.25 A, FERRITE CHIP

MMZ1005Y301CT Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerTDK Corporation
package instruction0402
Reach Compliance Codecompli
shell code0402
structureChip Bead
Maximum DC resistance0.38 Ω
filter typeFERRITE CHIP
maximum frequency400 MHz
minimum frequency80 MHz
high0.5 mm
JESD-609 codee3
length1 mm
Manufacturer's serial numberMMZ
MaterialFerrite
Installation typeSURFACE MOUNT
Number of functions1
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
Output impedance300 OHM Ω
method of packingTAPE AND REEL
physical sizeL1.0XB0.5XH0.5 (mm)/L0.039XB0.02XH0.02 (inch)
Rated current0.25 A
seriesMMZ1005
Terminal surfaceTIN
width0.5 mm
(1/4)
005-01 / 20050905 / e9412_mmz1005.fm
EMC Components
Ferrite Beads
SMD
FEATURES
• Size standardized for use by automatic assembly equipment. No
preferred orientation.
• Either flow or reflow soldering methods can be used due to
electroplating of the terminal electrodes.
• High reliability due to an entirely monolithic structure.
• Closed magnetic circuit structure allows high-density installation
while preventing crosstalk between circuits.
• Low DC resistance structure of electrode prevents wasteful
electric power consumption.
• It is a product conforming to RoHS directive.
APPLICATIONS
PCs, CRTs, liquid crystal display panels, printers, hard disk drives,
game machines, cellular phones, etc.
PRODUCT IDENTIFICATION
MMZ 1005 S 121 C T
(1)
(2) (3) (4) (5) (6)
(1) Series name
(2) Dimensions L
×
W
(3) Material code
(4) Nominal impedance
121:120
at 100MHz
(5) Characteristic type
(6) Packaging style
T:Taping
RECOMMENDED SOLDERING CONDITION
REFLOW SOLDERING
10s max.
250 to 260˚C
230˚C
Natural
cooling
MMZ Series MMZ1005 Type
Size: JIS/IEC 1005, EIA 0402
MATERIAL CHARACTERISTICS
B material: This type is perfectly suited for fast digital signals. By
equalizing R components and X components that
beads possess at a frequency of 5MHz, it is able to
suppress overshooting, undershooting and ringing of
fast digital signals.
S material: Standard type that features impedance characteristics
similar to those of a typical ferrite core.
For signal line applications in which the blocking region
is near 100MHz. Impedance values selected for effec-
tiveness at 40 to 300MHz.
Y material: High frequency range type intended for the 100MHz
region and above.
For signal line applications in which the signal fre-
quency is far from the cutoff frequency. Impedance val-
ues selected for effectiveness at 80 to 400MHz.
D material: For applications calling for low insertion loss at low fre-
quencies and sharply increasing impedance at high
frequencies. Designed for high impedance at high fre-
quencies (200 to 500MHz) for signal line applications.
F material: This new product inherits the characteristic of our D-
material, namely its sharp impedance rise time, and its
impedance peak frequency has been shifted higher
into range. The product offers excellent noise suppres-
sion from 600MHz to as high as in the GHz range.
TYPICAL MATERIAL CHARACTERISTICS
1500
Impedance(
)
1000
Y
S
D
F
500
180˚C
150˚C
Preheating
60 to 120s
Time(s)
Soldering
30 to 60s
0
1
10
100
Frequency (MHz)
1000
10000
• Conformity to RoHS Directive: This means that, in conformity with EU Directive 2002/95/EC, lead, cadmium, mercury, hexavalent chromium, and specific
bromine-based flame retardants, PBB and PBDE, have not been used, except for exempted applications.
• Please contact our Sales office when your application are considered the following:
The device’s failure or malfunction may directly endanger human life (e.g. application for automobile/aircraft/medical/nuclear power devices, etc.)
• All specifications are subject to change without notice.
