SCEP134H
SMD POWER INDUCTORS
XXX
MARKING
●
Features
1 Excellent Power Density
2 Engineered to Provide High Efficiency
ELECTRICAL CHARACTERISTICS
Part Number
Inductance
Test
DC Resistance
(uH)
Frequency
(Ω
MAX)
(1)
(2)
Saturation Temperature
(3)
(4)
Current
Current
(A)
(A)
Inductance (µH)
)
I nduct ance( uH
1000
SCEP134H
nduct ance decr ease by
by current
BCEP134H I
Inductance decrease
cur r ent
SCEP134H-R30
SCEP134H-R66
SCEP134H-1R2
SCEP134H-1R8
SCEP134H-2R7
SCEP134H-3R6
SCEP134H-4R8
SCEP134H-6R0
0.3
0.66
1.2
1.8
2.7
3.6
4.8
6.0
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
2.5m
3.2m
4.0m
6.6m
10.8m
12.0m
16.3m
18.4m
35.0
29.6
21.0
17.6
14.7
12.5
11.0
9.6
18.0
17.0
15.0
13.6
12.0
10.0
9.0
8.0
100
10
6R0
2R7
1
0R3
0. 1
10
100
1000
10000
100000
DC cur r ent (
(mA)
A)
DC current
m
BC
EP134H Tem
SCEP134H
per at ur e r i se
rise by
ent
Temperature
by cur r
current
Tem at ur e r i se ℃
per
80
70
60
50
40
30
20
10
0
2000
4000
6000
8000
10000 12000
14000 16000
18000
6R
0
2R
7
0R
3
Temperature rise °C
D
DC current (mA)
C cur r ent ( m
A)
(1). Inductance tolerance for 0.3uH~0.66uH:
±30%,
for 1.2uH~6.0uH:
±20%.
Tested at 0.25V, 0ADC and 25℃
(2). DCR measured at 25℃.
(3). The DC current at which the inductance decreases by 25% from its initial value.
(4). The DC current that results in a 40℃ temperature rise from 25℃ambient.
Click here for
QUANTITY PER REEL & PACKING INFORMATION
Custom versions available upon request.
www.signaltransformer.com
©
2011 Signal Transformer –Specification subject to change without notice. 07.11
500 Bayview Avenue, Inwood, NY 11096
Toll Free 866-239-5777 • Tel 516-239-5777 • Fax 516-239-7208
Sales@signaltransformer.com
•
techhelp@signaltransformer.com
