PM125SH-680M-RC datasheet, PDF

Datasheet> All Categories > Passive components> inductor> PM125SH-680M-RC

PM125SH-680M-RC: DescriptionFixed Inductors 68uH 20%; CategoryPassive components inductor; File Size213KB，2 Pages; ManufacturerBourns; Websitehttp://www.bourns.com; Environmental Compliance

Download Datasheet Parametric Compare View All

PM125SH-680M-RC Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	PM125SH-680M-RC	-	-	View	Buy Now

PM125SH-680M-RC Overview

Fixed Inductors 68uH 20%

PM125SH-680M-RC Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Bourns
package instruction	4949
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	12 weeks
uppercase and lowercase codes	4949
structure	Rectangular
core material	FERRITE
DC Resistance	110 Ω
Nominal inductance(L)	68 µH
Inductor Applications	POWER INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
JESD-609 code	e3
Number of functions	1
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
Package height	6 mm
Package length	12.5 mm
Package form	SMT
Package width	12.5 mm
method of packing	TR, EMBOSSED, 13 INCH
Maximum rated current	2.1 A
self resonant frequency	7.43 MHz
Shape/Size Description	RECTANGULAR PACKAGE
shield	YES
surface mount	YES
Terminal surface	Matte Tin (Sn)
Terminal location	DUAL ENDED
Terminal shape	ONE SURFACE
Test frequency	0.1 MHz
Tolerance	20%

Preview

Download Datasheet

View All

Features

■

Formerly

■

Available in E12 series

Applications

model

■

Input/output of DC/DC converters

■

Power supplies for:

■

Inductance as low as 1.0 µH

■

Current rating up to 9.4 A

■

RoHS compliant*

•

Portable communication equipment

Camcorders

LCD TVs

Car radios

PM125SH Series - Shielded SMD Power Inductor

Electrical Speciﬁcations

Inductance 100 kHz

General Speciﬁcations

Test

Q Frequency

Typ.

(MHz)

2.52

0.796

0.252

SRF

Typ.

(MHz)

21.00

19.40

17.60

15.50

13.40

12.70

9.97

10.40

7.63

7.92

7.43

6.85

6.07

5.50

5.00

4.50

4.20

3.60

3.20

2.80

2.60

2.40

2.20

2.00

1.80

RDC

Max.

(mΩ)

20.0

23.0

27.0

36.0

43.0

45.0

60.0

70.0

86.0

100.0

110.0

145.0

180.0

210.0

260.0

320.0

380.0

450.0

580.0

700.0

820.0

1000.0

1150.0

1500.0

1700.0

I rms

Max.

(A)

5.50

5.20

5.00

4.20

4.00

3.60

3.00

2.80

2.60

2.30

2.10

1.95

1.70

1.65

1.55

1.40

1.38

1.30

1.15

1.08

0.95

0.88

0.80

0.73

0.68

I sat

Typ.

(A)

5.50

5.00

4.60

3.90

3.70

3.30

2.80

2.70

2.50

2.20

2.10

1.90

1.70

1.65

1.55

1.40

1.30

1.20

1.10

1.00

0.90

0.80

0.75

0.63

0.60

Bourns Part No.

PM125SH-100M-RC

PM125SH-120M-RC

PM125SH-150M-RC

PM125SH-180M-RC

PM125SH-220M-RC

PM125SH-270M-RC

PM125SH-330M-RC

PM125SH-390M-RC

PM125SH-470M-RC

PM125SH-560M-RC

PM125SH-680M-RC

PM125SH-820M-RC

PM125SH-101M-RC

PM125SH-121K-RC

PM125SH-151K-RC

PM125SH-181K-RC

PM125SH-221K-RC

PM125SH-271K-RC

PM125SH-331K-RC

PM125SH-391K-RC

PM125SH-471K-RC

PM125SH-561K-RC

PM125SH-681K-RC

PM125SH-821K-RC

PM125SH-102K-RC

(µH)

100

120

150

180

220

270

330

390

470

560

680

820

1000

Tol. %

± 20

± 10

Test Voltage ....................................0.1 V

Reﬂow Soldering .. 230 °C, 50 sec. max.

Operating Temperature

................................-40 °C to +125 °C

(Temperature rise included)

Storage Temperature .. -40 °C to +125 °C

Resistance to Soldering Heat

............................... 260 °C for 10 sec.

Materials

Core ...........................Ferrite DR and RI

Wire ............ Enameled copper wire 130

Terminal ....................................Cu/Ni/Sn

Rated Current

...................Ind. drop 25 % typ. at Isat

Temperature Rise ................. 40 °C max.

at rated Irms

Packaging .................... 500 pcs. per reel

Product Dimensions

12.5

0.3

(.492

.012)

100

12.5

0.3

(.492

.012)

Electrical Schematic

Recommended Layout

REF.

5.4

(.213)

6.0

0.5

(.236

.020)

5.0

0.3

(.197

.012)

6.8

(.268)

REF.

2.9

(.114)

REF.

2.9

(.114)

REF.

7.0

TYP.

(.276)

DIMENSIONS:

(INCHES)

*RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.

Speciﬁcations are subject to change without notice.

Customers should verify actual device performance in their speciﬁc applications.

PM125SH-680M-RC Related Products

	PM125SH-680M-RC	PM125SH-180M-RC	PM125SH-220M	PM125SH-120M-RC	PM125SH-470M-RC	PM125SH-101M-RC	PM125SH-820M	PM125SH-330M	PM125SH-330M-RC	PM125SH-390M
Description	Fixed Inductors 68uH 20%	Fixed Inductors 18uH 20%	Fixed Inductors 22uH 20%	Fixed Inductors 12uH 20%	Fixed Inductors 47uH 20%	Fixed Inductors 100uH 20%	Fixed Inductors 82uH 20%	Fixed Inductors 33uH 20%	Fixed Inductors 33uH 20%	Fixed Inductors 39uH 20%
Is it Rohs certified?	conform to	conform to	incompatible	conform to	conform to	conform to	incompatible	incompatible	conform to	incompatible
Maker	Bourns	Bourns	Bourns	Bourns	Bourns	Bourns	Bourns	Bourns	Bourns	Bourns
package instruction	4949	4949	4747	4949	4949	4949	4747	4747	4949	4747
Reach Compliance Code	compliant	compliant	unknown	compliant	compliant	compliant	unknown	unknown	compliant	unknown
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
uppercase and lowercase codes	4949	4949	4747	4949	4949	4949	4747	4747	4949	4747
core material	FERRITE	FERRITE	FERRITE	FERRITE	FERRITE	FERRITE	FERRITE	FERRITE	FERRITE	FERRITE
DC Resistance	110 Ω	36 Ω	0.036 Ω	23 Ω	86 Ω	180 Ω	0.14 Ω	0.057 Ω	60 Ω	0.068 Ω
Nominal inductance(L)	68 µH	18 µH	22 µH	12 µH	47 µH	100 µH	82 µH	33 µH	33 µH	39 µH
Inductor Applications	POWER INDUCTOR	POWER INDUCTOR	POWER INDUCTOR	POWER INDUCTOR	POWER INDUCTOR	POWER INDUCTOR	POWER INDUCTOR	POWER INDUCTOR	POWER INDUCTOR	POWER INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR	GENERAL PURPOSE INDUCTOR
Number of functions	1	1	1	1	1	1	1	1	1	1
Number of terminals	2	2	2	2	2	2	2	2	2	2
Maximum operating temperature	125 °C	125 °C	100 °C	125 °C	125 °C	125 °C	100 °C	100 °C	125 °C	100 °C
Minimum operating temperature	-40 °C	-40 °C	-30 °C	-40 °C	-40 °C	-40 °C	-30 °C	-30 °C	-40 °C	-30 °C
Package height	6 mm	6 mm	6 mm	6 mm	6 mm	6 mm	6 mm	6 mm	6 mm	6 mm
Package length	12.5 mm	12.5 mm	12 mm	12.5 mm	12.5 mm	12.5 mm	12 mm	12 mm	12.5 mm	12 mm
Package form	SMT	SMT	SMT	SMT	SMT	SMT	SMT	SMT	SMT	SMT
Package width	12.5 mm	12.5 mm	12 mm	12.5 mm	12.5 mm	12.5 mm	12 mm	12 mm	12.5 mm	12 mm
method of packing	TR, EMBOSSED, 13 INCH	TR, EMBOSSED, 13 INCH	TR	TR, EMBOSSED, 13 INCH	TR, EMBOSSED, 13 INCH	TR, EMBOSSED, 13 INCH	TR	TR	TR, EMBOSSED, 13 INCH	TR
Maximum rated current	2.1 A	4.2 A	2.8 A	5.2 A	2.6 A	1.7 A	1.4 A	2.1 A	3 A	2 A
Shape/Size Description	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE
shield	YES	YES	YES	YES	YES	YES	YES	YES	YES	YES
surface mount	YES	YES	YES	YES	YES	YES	YES	YES	YES	YES
Terminal location	DUAL ENDED	DUAL ENDED	DUAL ENDED	DUAL ENDED	DUAL ENDED	DUAL ENDED	DUAL ENDED	DUAL ENDED	DUAL ENDED	DUAL ENDED
Terminal shape	ONE SURFACE	ONE SURFACE	ONE SURFACE	ONE SURFACE	ONE SURFACE	ONE SURFACE	ONE SURFACE	ONE SURFACE	ONE SURFACE	ONE SURFACE
Test frequency	0.1 MHz	0.1 MHz	0.001 MHz	0.1 MHz	0.1 MHz	0.1 MHz	0.001 MHz	0.001 MHz	0.1 MHz	0.001 MHz
Tolerance	20%	20%	20%	20%	20%	20%	20%	20%	20%	20%
Factory Lead Time	12 weeks	12 weeks	-	12 weeks	12 weeks	12 weeks	-	-	12 weeks	-
structure	Rectangular	Rectangular	-	Rectangular	Rectangular	Rectangular	-	-	Rectangular	-
JESD-609 code	e3	e3	-	e3	e3	e3	-	-	e3	-
self resonant frequency	7.43 MHz	15.5 MHz	-	19.4 MHz	7.63 MHz	6.07 MHz	-	-	9.97 MHz	-
Terminal surface	Matte Tin (Sn)	Matte Tin (Sn)	-	Matte Tin (Sn)	Matte Tin (Sn)	Matte Tin (Sn)	-	-	Matte Tin (Sn) - with Nickel (Ni) barrier	-
