CRCW1206R200JMTALR

Description
Thick Film Resistors - SMD 1/4watt .2ohms 5% Non Standard
CategoryPassive components
File Size115KB,5 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Download Datasheet Parametric View All

CRCW1206R200JMTALR Online Shopping

Suppliers Part Number Price MOQ In stock
CRCW1206R200JMTALR - - View Buy Now

CRCW1206R200JMTALR Overview

Thick Film Resistors - SMD 1/4watt .2ohms 5% Non Standard

CRCW1206R200JMTALR Parametric

Parameter NameAttribute value
Product CategoryThick Film Resistors - SMD
ManufacturerVishay
RoHSNo
Resistance0.2 Ohms
Power Rating0.25 W
Tolerance5 %
Temperature Coefficient300 PPM / C
Voltage Rating200 V
Operating Temperature Range- 55 C to + 155 C
Case Code - in1206
Case Code - mm3216
TypeChip Resistor
PackagingCut Tape
PackagingMouseReel
PackagingReel
Height0.55 mm
Length3.2 mm
Maximum Operating Temperature+ 155 C
Minimum Operating Temperature- 55 C
Package / Case1206 (3216 metric)
ProductThick Film Resistors SMD
Factory Pack Quantity5000
Termination StyleSMD/SMT
Width1.6 mm
Unit Weight0.000353 oz
D../CRCW....-LR is End of Life July 2009 and replaced by RCWL
D../CRCW....-LR
Vishay
Lead (Pb)-bearing Thick Film, Rectangular
Low Value Chip Resistor
FEATURES
Low resistance values (down to 0.1
Ω)
Suitable for current sensors and shunts
SnPb contacts on Ni barrier layer
Metal glaze on high quality ceramic
The RCWL is a direct replacement to the D../CRCW….-LR
type resistor with no change in performance or quality. For
RCWL datasheet please visit our website at
www.vishay.com/doc?20018
Protective overglaze
STANDARD ELECTRICAL SPECIFICATIONS
SIZE
MODEL
INCH METRIC
D10/CRCW0402-LR
D11/CRCW0603-LR
D12/CRCW0805-LR
D25/CRCW1206-LR
0402
0603
0805
1206
1005
1608
2012
3216
POWER RATING
P
70 °C
W
0.063
0.10
0.125
0.25
LIMITING
ELEMENT
VOLTAGE
MAX.
V≅
PxR
PxR
PxR
PxR
TEMPERATURE
COEFFICIENT
ppm/K
± 600
± 400
± 400
± 200
± 300
± 200
± 300
± 200
± 200
± 200
± 200
± 200
TOLERANCE
%
RESISTANCE
RANGE
Ω
0.22 to 0.43
0.47 to 0.91
0.10 to 0.43
0.47 to 0.91
0.10 to 0.43
0.47 to 0.91
0.10 to 0.43
0.47 to 0.91
0.10 to 0.91
0.10 to 0.91
0.10 to 0.91
0.10 to 0.91
E-SERIES
±5
±5
±5
±5
24
24
24
24
CRCW1210-LR
1210
3225
0.33
±5
24
PxR
CRCW1218-LR
1218
3246
1.0
±5
24
PxR
CRCW2010-LR
2010
5025
0.50
±5
24
PxR
CRCW2512-LR
2512
6332
1.0
±5
24
PxR
Notes
These resistors do not feature a limited lifetime when operated within the permissible limits. However, resistance value drift increasing over
operating time may result in exceeding a limit acceptable to the specific application, thereby establishing a functional lifetime.
Marking and packaging: See appropriate catalog or web page
Power rating depends on the max. temperature at the solder point, the component placement density and the substrate material
The resistance is measured from the top side
TECHNICAL SPECIFICATIONS
PARAMETER UNIT
D10/
D11/
D12/
D25/
CRCW1210-LR CRCW1218-LR CRCW2010-LR CRCW2512-LR
CRCW0402-LR CRCW0603-LR CRCW0805-LR CRCW1206-LR
Rated
W
0.063
0.1
0.125
0.25
0.33
1.0
0.5
1.0
Dissipation
at 70 °C
(2)
Rated Voltage V≅
PxR
Insulation
Voltage
V
peak
> 75
> 100
> 200
> 300
> 300
> 300
> 300
> 300
(1 min)
Thermal
K/W
870
550
440
220
140
65
88
65
Resistance
(1)
Insulation
Ω
> 10
9
Resistance
Category
°C
- 55 to + 155
Temp. Range
Failure Rate
h
-1
0.3 x 10
-9
Weight/
g
0.65
2
5.5
10
16
29.5
25.5
40.5
1000 pieces
Notes
(1)
For sizes 0402 until 1206 the measuring conditions are in acc. to EN 140401-802. For all other sizes the result depends on the solder pad
dimensions.
(2)
The power dissipation on the resistors generates a temperature rise against the local ambient, depending on the heat flow support of the
printed-circuit board (thermal resistance). The rated dissipation applies only if the permitted film temperature of 155 °C is not exceeded.
www.vishay.com
144
For technical questions, contact:
filmresistors.thickfilmchip@vishay.com
Document Number: 20010
Revision: 30-Apr-09
