High Temp Soldering: 250°C for 10 Seconds At Terminals
Surface Mount Package
Maximum Ratings
•
•
•
Operating
Junction
Temperature: -55°C to +150°C
Storage Temperature: -55°C to +150°C
500
mWatt DC Power Dissipation
Maximum Ratings @ 25
o
C Unless Otherwise Specified
Zener Current
I
F
100
mA
Maximum Forward
V
F
1.2
V
Voltage
Power Dissipation
P
(AV)
410
mWatt
(No te s A)
Pe ak Forward S urge I
FSM
4.0
Amps
Current (Not e s B)
NOTES:
A. Mounted on 5.0mm2(.013mm thick) land areas.
B. Measured on 8.3ms, single half sine-wave or equivalent
square wave, duty cycle = 4 pulses per minute maximum
.
C
B
E
F
J
G
H
K
DIMENSIONS
DIM
A
B
C
D
E
F
G
H
J
K
INCHES
MIN
.110
.086
.047
.033
.066
---
.035
.002
.013
.007
MAX
.119
.103
.056
.041
.083
.006
.044
.006
.020
---
MM
MIN
2.80
2.20
1.20
.85
1.70
---
.90
.05
.35
.20
MAX
3.00
2.60
1.40
1.05
2.10
.15
1.10
.15
.50
---
NOTE
Suggested Solder
Pad Layout
.035
.900
*Pin Configuration - Top View
.055
1.40
.102
2.60
inches
mm
.035
.880
.035
.880
www.mccsemi.com
MMBZ5221B thru MMBZ5259B
Electrical Characteristics @ 25
o
C Unless Otherwise Specified
MCC PART
NUMBER
NORMAL
ZENER
VOLTAGE
Vz@ Izt
TEST
CURRENT Izt
MAXIMUM ZENER
IMPEDANCE
‘B’ SUFFIX ONLY
Zzt @ Izt Zzk @ Izk=0.25mA
MCC
MAXIMUM REVERSE
LEAKAGE CURRENT
Ir @ Vr
MAXIMUM ZENER
VOLTAGE TEMP
COEFFICIENT ‘B’
SUFFIX ONLY
Marking
VOLTS
mA
OHMS
OHMS
uA
VOLTS
%/
o
C
MMBZ5221B
MMBZ5222B
MMBZ5223B
MMBZ5225B
MMBZ5226B
MMBZ5227B
MMBZ5228B
MMBZ5229B
MMBZ5230B
MMBZ5231B
MMBZ5232B
MMBZ5234B
MMBZ5235B
MMBZ5236B
MMBZ5237B
MMBZ5239B
MMBZ5240B
MMBZ5241B
MMBZ5242B
MMBZ5243B
MMBZ5245B
MMBZ5246B
MMBZ5248B
MMBZ5250B
MMBZ5251B
MMBZ5252B
MMBZ5254B
MMBZ5255B
MMBZ5256B
MMBZ5257B
MMBZ5258B
MMBZ5259B
C1
C2
C3
C5
D1
D2
D3
D4
D5
E1
E2
E4
E5
F1
F2
F4
F5
H1
H2
H3
H5
J1
J3
J5
K1
K2
K4
K5
M1
M2
M3
M4
2.4
2.5
2.7
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
28
30
33
36
39
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
9.5
8.5
7.8
7.0
6.2
5.6
5.2
4.6
4.5
4.2
3.8
3.4
3.2
30
30
30
29
28
24
23
22
19
17
11
7.0
5.0
6.0
8.0
10
17
22
30
13
16
17
21
25
29
33
41
44
49
58
70
80
1200
1250
1300
1600
1600
1700
1900
2000
1900
1600
1600
1000
750
500
500
600
600
600
600
600
600
600
600
600
600
600
600
600
600
700
700
800
100
100
75
50
25
15
10
5.0
5.0
5.0
5.0
5.0
3.0
3.0
3.0
3.0
3.0
2.0
1.0
0.5
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
2.0
2.0
3.0
4.0
5.0
6.0
6.5
7.0
8.0
8.4
9.1
9.9
11
12
14
15
17
18
21
21
23
25
27
30
-0.085
-0.085
-0.080
-0.075
-0.070
-0.065
-0.060
±0.055
±0.030
±0.030
+0.038
+0.045
+0.050
+0.058
+0.062
+0.068
+0.075
+0.076
+0.077
+0.079
+0.082
+0.083
+0.085
+0.086
+0.087
+0.088
+0.090
+0.091
+0.091
+0.092
+0.093
+0.094
NOTE:
1.Tolerance and Type Number Designation. The type numbers listed have a standard tolerance on the nominal zener voltage of ±5%.
2. Specials Available Include:
A. Nominal zener voltages between the voltages shown and tighter voltage tolerances.
B. Matched sets.
3. Zener Voltage (V
Z
) Measurement. Guarantees the zener voltage when measured at 90 seconds while maintaining the lead temperature (T
L
) at 30
O
C, from the diode body.
4.Zener Impedance (Z
Z
) Derivation. The zener impedance is derived from the 60 cycle ac voltage, which results when an AC current having an rms value equal to 10% of the dc zener
current (I
ZT
or I
ZK
) is superimposed on I
ZT
or I
ZK
.
5.Surge Current (I
R
) Non-Repetitive. The rating listed in the electrical characteristics table is maximum peak, non-repetitive, reverse surge current of 1/2 square wave or equivalent sine
wave pulse of 1/120 second duration superimposed on the test current, I
ZT
, per JEDEC registration; however, actual device capability is as described in Figure 5.
