P
ER
ET
e)
AM
nc
DI
re
fe
AD
Re
B
LE
,
es
N
ch
IO
e)
(In
NS
enc
ME
er
DI
ef
,R
L
es
TA
ch
EN C)
(In
EM A D
CR T (
IN
EN NG
RR
TI )
CU
RA C
T AD
EN M (
RR U
E
CU XIM ANC
MA IST 25°C
S
RE S) @
DC HM
E
(O
NC
M
RA
MU
LE
XI
TO
L
MA
NA
MI H)
NO E (µ
C
AN
*
CT
ER
DU
IN
MB
NU
s
or
ct
du
In
er
ow
SERIES
DC630R
DC630
DA
SH
High Current Power Line Chokes
Actual Size
Physical Parameters
Inches
Millimeters
A
0.630 ± 0.030
16.0 ± 0.762
B (C/L to C/L) See Characteristics table
C
0.750 Min.
19.05 Min.
D
0.810 ± 0.020
20.57 ±0.508
E (Ref. only)
0.195 Max.
4.95 Max.
F
Clearance Hole for 4/40 Screw
Leads Tinned to within 1/16" of Body
Inductance
Measured @ 10 KHz, 25mAdc and 0 Adc @ 25°C
Mechanical Configuration
Center hole allows for
mechanical mounting
Operating Temperature
–55°C to +125°C;
–55°C to +80°C @ full rated current
Current Rating at 80°C Ambient
45°C Rise
Incremental Current
Minimum current which causes a
5% max. change in Inductance
Power Dissipation at 80°C
1.00 Watts Max.
Dielectric Withstanding Voltage
1000 V RMS Min.
Marking
DELEVAN; DC630; dash number with tolerance
letter. Note: An R after DC630 indicates a RoHS
component.
Example: DC630-102M
DELEVAN
DC630
102M
Packaging
Bulk only
-102M
-152M
-222M
-272M
-332M
-392M
-472M
-562M
-682M
-822M
-103K
-123K
-153K
-183K
-223K
-273K
-333K
-393K
-473K
-563K
-683K
-823K
-104K
-124K
-154K
-184K
-224K
-274K
-334K
-394K
-474K
-564K
-684K
1.0
1.5
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10.0
12.0
15.0
18.0
22.0
27.0
33.0
39.0
47.0
56.0
68.0
82.0
100
120
150
180
220
270
330
390
470
560
680
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 20%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
± 10%
SERIES
0.003
0.004
0.005
0.005
0.005
0.006
0.007
0.007
0.008
0.009
0.010
0.011
0.015
0.020
0.025
0.030
0.040
0.050
0.062
0.069
0.077
0.083
0.095
0.100
0.111
0.125
0.168
0.225
0.315
0.342
0.377
0.408
0.468
DC630
14.00
13.50
12.80
12.80
12.80
12.30
11.70
11.70
10.50
10.00
9.50
9.10
8.09
7.00
6.26
5.72
4.95
4.43
3.98
3.77
3.57
3.44
3.21
3.12
2.97
2.80
2.42
2.09
1.72
1.66
1.58
1.52
1.42
68.0
55.5
46.0
42.0
38.0
34.5
31.5
29.0
26.0
24.0
21.5
19.5
17.5
16.0
14.5
13.2
11.9
10.9
10.0
9.20
8.30
7.60
6.80
6.20
5.60
5.10
4.60
4.20
3.80
3.40
3.10
2.90
2.60
0.490
0.490
0.490
0.490
0.490
0.490
0.490
0.490
0.490
0.490
0.490
0.490
0.470
0.460
0.460
0.440
0.430
0.420
0.480
0.480
0.480
0.480
0.480
0.480
0.480
0.480
0.470
0.450
0.450
0.480
0.480
0.480
0.480
0.051
0.051
0.051
0.051
0.051
0.051
0.051
0.051
0.051
0.051
0.051
0.051
0.045
0.040
0.040
0.036
0.032
0.029
0.029
0.029
0.029
0.029
0.029
0.029
0.029
0.029
0.025
0.023
0.020
0.020
0.020
0.020
0.020
*Complete part # must include series # PLUS the dash #
For surface finish information, refer to www.delevanfinishes.com
270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814 • E-mail: apisales@delevan.com • www.delevan.com
1/2009
