ELECTRIC DOUBLE LAYER CAPACITORS "EVerCAP "
JJC
Snap-in Terminal Type
Excellent in voltage holding property.
Suitable for quick charge and discharge.
Wide temperature range
(
–
25
°C to +
60
°C).
Compliant to the RoHS directive (2011/65/EU).
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Stability at Low Temperature
ESR, DCR*
Endurance
– 25 to +60°C
2.5V
56 to 200F
See Note
± 20% (20°C)
Performance Characteristics
Capacitance (
– 25°C) /
Capacitance (+
20°C)
×
100
70%
ESR (
– 25°C) /
ESR (+
20°C)
7
Refer to the table below (
20°C
). *DC internal resistance
The specifications listed at right shall be met when the capacitors
are restored to 20°C after the rated voltage is applied for 2000 hours
at 60°C.
Capacitance change
ESR
Within ±30% of the initial capacitance value
300% or less than the initial specified value
Shelf Life
The specifications listed at right shall be met when the capacitors
are restored to 20°C after storing the capacitors under no load
for 2000 hours at 60°C.
The specifications listed at right shall be met when the capacitors
are restored to 20°C after the rated voltage is applied for 500 hours
at 40°C 90%RH.
Printed with white color letter on black sleeve.
Capacitance change
ESR
Within ±30% of the initial capacitance value
300% or less than the initial specified value
Capacitance change
Humidity Endurance
Marking
ESR
Within ±30% of the initial capacitance value
300% or less than the initial specified value
Drawing
Polarity bar
Sleeve (P.E.T.)
Type numbering system (Example : 2.5V 150F)
1
2
3
4
5
6
7
8
9
10 11 12
J J C 0 E 1 5 7 M E L C
φD
+1MAX.
L
±2
4.0±0.5
(10
)
Case dia. code
Configuration
Capacitance tolerance (±20%)
φD
25
30
35
Code
A
B
C
Pressure relief vent
0.8
+0.2
-0.1
4.0 ±
0.5
0.8
.2
+0 .1
-0
Rated capacitance (150F)
Rated voltage (2.5V)
Series name
(2.5)
Type
1.5
+0.2
-0.1
(Terminal dimensions)
Dimensions
Rated
Voltage
( code )
Cap.
(F)
Cap.
code
ESR(mΩ)
(at 1kHz )
DCR
Typical
(mΩ)
Case size
φ
D
×
L (mm)
φ
25 (A)
φ
30 (B)
φ
35 (C)
56
68
2.5V
(0E)
82
100
120
150
200
566
686
826
107
127
157
207
70
60
60
50
50
40
30
50
45
35
30
25
22
16
25
×
40
25
×
50
30
×
30
35
×
30
30
×
40
35
×
35
30
×
50
35
×
40
35
×
50
35
×
50
Note :
The capacitance calculated from discharge time (ΔT) with
constant current ( i ) after 30minuite charge with rated
voltage (2.5V).
The discharge current ( i ) is 0.01
×
rated capacitance (F).
The discharge time (ΔT) measured between 2V and 1V
with constant current.
The capacitance calculated bellow.
Capacitance (F) = i
× ΔT
The listed DCR value is typical and therefore not a guaranteed value.
