This document was generated on 09/02/2014
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
39-00-0281
Active
Standard .093" Pin and Socket Connectors
2.36mm Diameter, Standard .093" Pin and Socket Crimp Terminal, Series 1189,
Female, with Tin (Sn) over Copper Plated Brass Contact, 14-20 AWG, Reel
Documents:
Drawing (PDF)
Product Specification PS-1189-009 (PDF)
Product Specification PS-3191-003 (PDF)
Product Specification PS-3191-004 (PDF)
RoHS Certificate of Compliance (PDF)
Series
image - Reference only
General
Product Family
Series
Application
Crimp Quality Equipment
Overview
Product Name
UPC
Crimp Terminals
1189
Power
Yes
Standard .093" Pin and Socket Connectors
Standard .093"
800753584815
EU RoHS
ELV and RoHS
Compliant
REACH SVHC
Contains SVHC: No
Low-Halogen Status
Low-Halogen
China RoHS
Physical
Gender
Material - Metal
Material - Plating Mating
Material - Plating Termination
Net Weight
Packaging Type
Plating min - Mating
Plating min - Termination
Termination Interface: Style
Wire Insulation Diameter
Wire Size AWG
Wire Size mm²
Female
Brass
Tin
Tin
339.000/mg
Reel
0.889µm
0.889µm
Crimp or Compression
1.60-4.10mm
14, 16, 18, 20
N/A
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
1189Series
Use With
1375 Receptacle, 1490 Receptacle,
1545 Receptacle, 1261 Receptacle,
1951 Receptacle, 1396 Receptacle,
2629 Receptacle, 2163 Receptacle,
1619 Receptacle, 1292 Receptacle, 1360
Receptacle
Application Tooling
|
FAQ
Tooling specifications and manuals are
found by selecting the products below.
Crimp Height Specifications are then
contained in the Application Tooling
Specification document.
Global
Description
Product #
Mini-Mac™
0638927300
Applicator
Extractor Tool
0638240200
for .093 and
HCS-125 Product
Series
Material Info
Old Part Number
1189AT
Reference - Drawing Numbers
Crimp Specification
Product Specification
Sales Drawing
CS-1189_1190
PS-1189-009, PS-3191-003, PS-3191-004,
RPS-1189-001, RPS-3191-002, RPS-3191-005
SD-1189-002
