Printed-circuit board connector - MVSTBR 2,5/ 4-ST-5,08 BU - 1849079
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Plug component, Nominal current: 12 A, Number of positions: 4, Pitch: 5.08 mm, Connection method: Screw
connection with tension sleeve, Color: blue, Contact surface: Tin
Key Commercial Data
Packing unit
Weight per Piece (excluding packing)
Custom tariff number
Country of origin
1 pc
8.8 g
85366990
Germany
Technical data
Dimensions
Pitch
Dimension a
5.08 mm
15.24 mm
General
Range of articles
Rated voltage (III/3)
Connection in acc. with standard
Nominal current I
N
Nominal cross section
Number of positions
MVSTBR 2,5/..-ST
250 V
EN-VDE
12 A
2.5 mm²
4
Connection data
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Conductor cross section flexible, with ferrule without plastic sleeve min.
Conductor cross section flexible, with ferrule without plastic sleeve max.
Conductor cross section flexible, with ferrule with plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve max.
Conductor cross section AWG min.
0.2 mm²
2.5 mm²
0.2 mm²
2.5 mm²
0.25 mm²
2.5 mm²
0.25 mm²
2.5 mm²
24
04/19/2016 Page 1 / 4
https://www.phoenixcontact.com/us/products/1849079
Printed-circuit board connector - MVSTBR 2,5/ 4-ST-5,08 BU - 1849079
Technical data
Connection data
Conductor cross section AWG max.
2 conductors with same cross section, solid min.
2 conductors with same cross section, solid max.
2 conductors with same cross section, stranded min.
2 conductors with same cross section, stranded max.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, min.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, max.
12
0.2 mm²
1 mm²
0.2 mm²
1.5 mm²
0.25 mm²
1 mm²
2 conductors with same cross section, stranded, TWIN ferrules with plastic
0.5 mm²
sleeve, min.
2 conductors with same cross section, stranded, TWIN ferrules with plastic
1.5 mm²
sleeve, max.
Minimum AWG according to UL/CUL
Maximum AWG according to UL/CUL
30
12
Standards and Regulations
Connection in acc. with standard
EN-VDE
CSA
Classifications
eCl@ss
eCl@ss 4.0
eCl@ss 4.1
eCl@ss 5.0
eCl@ss 5.1
eCl@ss 6.0
eCl@ss 7.0
eCl@ss 8.0
eCl@ss 9.0
272607xx
27260701
27260701
27141190
27260704
27440402
27440309
27440309
ETIM
ETIM 3.0
ETIM 4.0
ETIM 5.0
EC001121
EC002638
EC002638
UNSPSC
UNSPSC 6.01
UNSPSC 7.0901
30211810
39121409
04/19/2016 Page 2 / 4
https://www.phoenixcontact.com/us/products/1849079
Printed-circuit board connector - MVSTBR 2,5/ 4-ST-5,08 BU - 1849079
Classifications
UNSPSC
UNSPSC 11
UNSPSC 12.01
UNSPSC 13.2
39121409
39121409
39121409
Approvals
Approvals
Approvals
CSA / VDE Gutachten mit Fertigungsüberwachung / IECEE CB Scheme / EAC / cULus Recognized / EAC
Ex Approvals
Approvals submitted
Approval details
CSA
VDE Gutachten mit Fertigungsüberwachung
IECEE CB Scheme
EAC
cULus Recognized
mm²/AWG/kcmil
Nominal current IN
B
30-12
15 A
D
30-12
10 A
04/19/2016 Page 3 / 4
https://www.phoenixcontact.com/us/products/1849079
Printed-circuit board connector - MVSTBR 2,5/ 4-ST-5,08 BU - 1849079
Approvals
Nominal voltage UN
B
300 V
D
300 V
EAC
