MIL-DTL-83513
Micro-D
500-047
EMI/RFI Elliptical Entry
Micro-D Banding Backshell
Elliptical Backshells
provide extra room for
large wire bundles. This one piece version
features an oversize shield termination area
for both standard and micro BandMaster™
ATS shield termination straps.
Materials
• Shell: Aluminum Alloy 6061 -T6
• Clips: 17-7PH Stainless Steel
• Hardware: 300 Series Stainless Steel
How To Order EMI/RFI Elliptical Backshells
Sample Part Number
Series
Shell Finish
Connector Size
Hardware Option
EMI Band Strap Option
Qwik-Ty Option
500-047
E
– Chem Film (Alodyne)
M
– Electroless Nickel
B
– Fillister Head Jackscrew
E
– Extended Jackscrew
J
– Cadmium, Yellow Chromate
NF
– Cadmium, Olive Drab
H
– Hex Head Jackscrew
F
– Jackpost, Female
Z2
– Gold
500-047
M
25
H
T
09, 15, 21, 25, 31, 37 51, 51-2, 67, 69, 100
(See Table I)
(See Table I)
Omit
(Leave Blank) – Band Not Included
B
– Standard Band .250" Wide, uncoiled
M
– Micro Band .125" Wide, uncoiled
T
– with Qwik-Ty
Omit
for none
Table I: Dimensions
Hardware Option
CONFIGURATION MFR
OPTION APPLY TO
MALE JACKSCREW
C
.175
.30
RETAINING CLIP
B
J THREAD - TYP
B
- Fillister Head Jackscrew
H
- Hex Head Jackscrew
A
G
CONNECTOR
SHOWN
FOR REFERENCE
ONLY
D
E
- Extended Jackscrew
JACKSCREW
H
F
E
QWIK-TY
SYM T
F
- Jackpost, Female
G
H Ref.
In.
mm.
.154
3.91
.154
.154
.154
.154
.154
.154
.154
.154
.184
3.91
3.91
3.91
3.91
3.91
3.91
3.91
3.91
4.67
J Thread
2-56 UNC-2A
2-56 UNC-2A
2-56 UNC-2A
2-56 UNC-2A
2-56 UNC-2A
2-56 UNC-2A
2-56 UNC-2A
2-56 UNC-2A
2-56 UNC-2A
4-40 UNC-2A
Rev. 04.01.16
Printed in U.S.A.
Size
09
15
21
25
31
37
51
51-2
69
100
A
In.
.775
.925
1.075
1.175
1.325
1.475
1.425
1.835
1.730
2.160
mm.
19.69
23.50
27.31
29.85
33.66
37.47
36.20
46.61
43.94
54.86
In.
.34
.34
.34
.34
.34
.34
.38
.34
.40
.43
B
mm.
8.64
8.64
8.64
8.64
8.64
8.64
9.65
8.64
10.16
10.92
In.
.75
.88
1.00
1.06
1.12
1.16
1.19
1.19
1.19
1.25
C
mm.
19.05
22.35
25.40
26.92
28.45
29.46
30.23
30.23
30.23
31.75
D Dia
In.
mm.
.312
7.92
.420
.590
.690
.820
.970
.920
1.030
1.190
1.290
10.67
14.99
17.53
20.83
24.64
23.37
26.16
30.23
32.77
E Dia
In.
mm.
.281
7.14
.281
.281
.281
.281
.281
.312
.281
.312
.360
7.14
7.14
7.14
7.14
7.14
7.92
7.14
7.92
9.14
F
In.
.32
.44
.56
.62
.68
.72
.75
.75
.75
.81
mm.
8.13
11.18
14.22
15.75
17.27
18.29
19.05
19.05
19.05
20.57
In.
.565
.715
.865
.965
1.115
1.265
1.215
1.615
1.515
1.800
mm.
14.35
18.16
21.97
24.51
28.32
32.13
30.86
41.02
38.48
45.72
© 2011 Glenair, Inc.
CAGE Code 06324
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
C-24
