Ring Terminal, Non-Insulated
• Ring tongue design assures a secure connection in high
vibration applications
• Internal barrel serrations assure good wire contact and
maximum tensile strength
• Brazed seam protects terminal barrel from splitting during
the crimp process
• Barrel of terminal internally beveled to provide quick and
easy wire insertion
• Maximum recommended operating temperature
302°F (150°C)
• UL and CSA rated up to 2000 V per UL 486A/B,
where applicable
A.
System
Overview
B.
Copper
Systems
C.
Fiber
Optic
Systems
D.
Power
over
Ethernet
E.
Zone
Cabling
L
W
C
Wire
Range
Part Number
P14-8R-C
P14-10R-C
P14-14R-C
P14-56R-C
P14-38R-C
P14-12R-L
P10-8R-L
P10-10R-L
P10-14R-L
P10-56R-L
P10-38R-L
P10-12R-L
P8-10R-Q
P8-14R-Q
P8-56R-Q
P8-38R-Q
P8-12R-Q
P6-10R-E
P6-14R-E
P6-56R-E
P6-38R-E
P6-12R-E
P4-14R-E
P4-56R-E
P4-38R-E
P4-12R-E
P2-14R-X
P2-56R-X
P2-38R-X
P2-12R-X
2 AWG
35.0
4 AWG
25.0
6 AWG
16.0
8 AWG
10.0
14 – 10
AWG
2.5 – 6.0
18 – 14
AWG
1.0 – 2.5
AWG
mm
2
F.
Wireless
Stud
Size
In.
#8
#10
1/4"
5/16"
3/8"
1/2"
#8
#10
1/4"
5/16"
3/8"
1/2"
#10
1/4"
5/16"
3/8"
1/2"
#10
1/4"
5/16"
3/8"
1/2"
1/4"
5/16"
3/8"
1/2"
1/4"
5/16"
3/8"
1/2"
mm
M4
M5
M6
M8
M10
M12
M4
M5
M6
M8
M10
M12
M5
M6
M8
M10
M12
M5
M6
M8
M10
M12
M6
M8
M10
M12
M6
M8
M10
M12
Length
In.
0.71
0.71
0.91
0.91
1.0
1.20
0.78
0.81
0.96
0.96
1.05
1.20
1.14
1.14
1.25
1.25
1.36
1.21
1.21
1.33
1.33
1.43
1.40
1.46
1.46
1.55
1.46
1.46
1.46
1.55
mm
18.0
18.0
23.1
23.1
25.4
30.5
19.8
20.6
24.4
24.4
26.7
30.5
29.0
29.0
31.8
31.8
34.5
30.7
30.7
33.8
33.8
36.3
35.6
37.1
37.1
39.4
37.1
37.1
37.1
39.4
Width
In.
0.31
0.31
0.46
0.46
0.53
0.72
0.31
0.38
0.52
0.52
0.58
0.72
0.47
0.47
0.59
0.59
0.82
0.47
0.47
0.62
0.62
0.82
0.55
0.68
0.68
0.86
0.68
0.68
0.68
0.86
mm
7.9
7.9
11.7
11.7
13.5
18.3
7.9
9.7
13.2
13.2
14.7
18.3
11.9
11.9
15.0
15.0
20.8
11.9
11.9
15.7
15.7
20.8
14.0
17.3
17.3
21.8
17.3
17.3
17.3
21.8
Clearance
In.
0.25
0.25
0.38
0.38
0.43
0.53
0.31
0.31
0.38
0.38
0.44
0.53
0.43
0.43
0.51
0.51
0.54
0.43
0.43
0.51
0.51
0.51
0.50
0.50
0.50
0.53
0.58
0.58
0.58
0.58
mm
6.4
6.4
9.7
9.7
10.9
13.5
7.9
7.9
9.7
9.7
11.2
13.5
10.9
10.9
13.0
13.0
13.7
10.9
10.9
13.0
13.0
13.0
12.7
12.7
12.7
13.5
14.7
14.7
14.7
14.7
Panduit
Crimping
Tool
CT-100A‡,
CT-200‡,
CT-600-A‡,
CT-1570‡,
CT-2500‡
Std. Std.
Pkg. Ctn.
Qty. Qty.
100 1000
100
100
100
100
50
50
1000
1000
1000
1000
500
500
500
500
500
500
500
250
250
250
250
250
200
200
200
200
200
200
200
200
200
100
100
100
100
G.
Outlets
H.
Media
Distribution
I.
Physical
Infrastructure
Management
J.
Overhead &
Underfloor
Routing
K.
Surface
Raceway
L.
Cabinets,
Racks &
Cable
Management
M.
Grounding &
Bonding
CT-100A‡,
CT-200‡,
CT-600-A‡,
CT-1570‡,
CT-1701‡,
CT-2500‡
50
50
50
50
50
25
25
25
25
25
20
20
20
20
20
20
CT-1701‡,
CT-2600 with Die Insert
CD-2600-8‡
CT-1701‡,
CT-2600 with Die Insert
CD-2600-6‡
CT-1701‡,
CT-2600 with Die Insert
CD-2600-4‡
20
20
20
10
CT-1701‡,
CT-2600 with Die Insert
CD-2600-4‡
10
10
10
N.
Industrial
‡UL and CSA approved tooling/product combinations.
For crimping tool information, see page M.46
of SA-NCCB51.
For the full selection of Panduit Crimping Tools see www.panduit.com.
