This document was generated on 10/03/2017
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0850132036
Active
DIN 41612
2.54mm Pitch DIN 41612 Header, Through Hole, Vertical, Style R/2 Reverse, 1µm
Selective Gold (Au), 48 Circuits, Lead-Free
Documents:
3D Model
Drawing (PDF)
Agency Certification
CSA
UL
General
Product Family
Series
Application
Comments
Component Type
Overview
Product Name
Style
UPC
Physical
Circuits (Loaded)
Circuits (maximum)
Circuits Detail
Durability (mating cycles max)
First Mate / Last Break
Flammability
Guide to Mating Part
Keying to Mating Part
Material - Plating Mating
Net Weight
Number of Columns
Number of Pairs
Number of Rows
Orientation
PC Tail Length
PCB Locator
PCB Retention
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Polarized to PCB
Stackable
Surface Mount Compatible (SMC)
Temperature Range - Operating
Electrical
Current - Maximum per Contact
Data Rate
Real Signals (per 25mm)
Shield Type
RoHS Certificate of Compliance (PDF)
Series image - Reference only
LR19980
E29179
Backplane Connectors
85013
Daughtercard
4 Day Industrial Environment (S02)
PCB Header
DIN 41612
IEC 603-2/DIN 41612
R/2
800756596433
48
48
Rows A, B, & C
500
No
94V-0
No
Yes
Gold
7.139/g
16
Open Pin Field
3
Vertical
13.30mm
No
Yes
Bag
2.54mm
2.54mm
1.016µm
No
No
No
-55°C to +125°C
1.0A
622.0 Mbps
30
N/A
EU ELV
Not Relevant
EU RoHS
China RoHS
Compliant
REACH SVHC
Not Contained Per -
ED/30/2017 (7 July
2017)
Halogen-Free
Status
Not Low-Halogen
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Green Image
Not Relevant
Not Contained
Search Parts in this Series
85013 Series
Mates With
85042 , 85052 Backplane Header
Shielded
Voltage - Maximum
Solder Process Data
Duration at Max. Process Temperature (seconds)
Lead-freeProcess Capability
Process Temperature max. C
Material Info
Reference - Drawing Numbers
Sales Drawing
No
1000V (RMS)
010
WAVE
260
E-85013-0002, E-85013-2036, SD-85013-2036,
SDA-85013-0002, SDA-85013-2036
This document was generated on 10/03/2017
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
