F
E
D
C
B
A
22,98
`
0,3
2,6
+ 0,1
-0
7
`
0,1
D
2,08
`
0,1
11,3
`
0,3
D
Ø4,8
+ 0
- 0,05
1
3
2
C
Ø4,6
+0,15
-0
Ø5,8
`
0,1
C
b
NOTES:
1. MATERIAL: COPPER ALLOY
2. PLATING:
ITEM 1: SEE TABLE
ITEM 2: GOLD FLASH over NICKEL
ITEM 3: NICKEL PLATED
3. CRIMPING: USE CRIMP TOOL 360X10409X
WITH TOOL INSERT 360X20029X
SELECTOR SETTINGS: 7 FOR AWG 8
6 FOR AWG 10
c 4. CURRENT RATING: PER UL 1977 / CSA - C22.2 No.182.3 ( E228329 )
-40A
B
-50A only when used with cable AWG 8 and in combination with
2W2C connectors per following part number system:
Cat. No. 302W2, 302W2 followed by C, followed by P or S,
followed by XX, followed by 99, followed by A1 through A8, C1 through C6,
D1 through D6, E1 through E6, F1 through F6, G1 through G4,
H1 through H4, K1 through K4, L1 through L4, N1 through N4 or
P1 through P4, W1, W2 or S9, followed by 0X or 0A to 0W
when used in conjunction with the following contacts and
pins 131A, 132A, 131C, 132C, 131J and 132J followed by 11049X
7,5
b
PLATING ITEM 1
GOLD FLASH over NICKEL
min. 30µin HARD GOLD over min. 50µin NICKEL
min. 50µin HARD GOLD over min. 50µin NICKEL
THIS DRAWING MAY NOT BE COPIED OR
REPRODUCED IN ANY WAY, AND MAY NOT
BE PASSED ON TO A THIRD PARTY WITHOUT
WRITTEN PERMISSION.
OWNERSHIP AND COPYRIGHT OF CONEC GmbH
B
PART-NO.
132A11049X
132C11049X
132J11049X
5:1
SEE NOTES
A
b
STRIPPING DIMENSIONS
DO NOT ALTER CAD DRAWING BY HAND
finish
SEE NOTES
tolerance
ISO 2768-m
date
drawn
23.03.98
scale:
material:
dim. in mm
name
A
title:
Barcinski
HIGH POWER CONTACT FEMALE
CRIMP VERSION AWG 8-10
D-SUB COMBINATION
dwg no:
R
appd.
23.03.98 Mickenbecker
norm
c
DIN-
A3
sh:
1
A
b
2xc
4xb
a
Ä4283
Ä3854
Origin
17.04.12
19.01.11
K.H.
K.H.
d-old
13K1IF0A
part no:
Directive 2002/95/EC RoHS compliant
F
E
rev. description
D
date
name
C
SEE TABLE
B
