EEWORLDEEWORLDEEWORLD

Part Number

Search

322-HCS5P3-640

Description
DIP40, IC SOCKET
CategoryThe connector    socket
File Size140KB,2 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Environmental Compliance
Download Datasheet Parametric View All

322-HCS5P3-640 Overview

DIP40, IC SOCKET

322-HCS5P3-640 Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerTE Connectivity
Reach Compliance Codeunknown
ECCN codeEAR99
Contact to complete cooperationNOT SPECIFIED
Contact materialNOT SPECIFIED
Device slot typeIC SOCKET
Type of equipment usedDIP40
Manufacturer's serial number322-HCS5P3-640
Number of contacts40
Base Number Matches1
This browser does not have Java enabled.
TE Connectivity
 My Cart |
 My Part Lists | Sign In/Register
English
(Change)
Have a Question?
Chat with a Product
Information Specialist
What can we help you find?
Products
Industries
Resources
About TE
My Account
Innovation
Support Center
Home > Products > Socket/Card Products > Product Feature Selector > Product Details
322­HCS5P3­640 Product Details
DIP Sockets

Always EU RoHS compliant but not ELV Compliant
 (
Statement of
No Image Available
Compliance
)
 Share
 Print
 Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
322­HCS5P3­640
(147841­3)
TE Internal Number: 147841­3
Product Highlights:
Socket Style = Standard
Through Hole Contact Termination Type
2.54 mm Centerline
Row­to­Row Spacing = 15.24 mm
40 Positions
View all Features
 Preliminary
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
None Available
Catalog Pages/Data Sheets:
None Available
Product Specifications:
None Available
Application Specifications:
AUGAT HOLTITE Sockets (PDF, English)
Instruction Sheets:
None Available
CAD Files:
None Available
Additional Information:
Product Line Information
Additional Product Images:
Product Photo
Related Products:
Tooling
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Profile = Zero
Frame Style = Film Carrier
Leg Style = Straight
Electrical Characteristics:
Contact Resistance (mΩ) = 10
Contact Rating = 3A
Termination Features:
Contact Termination Type = Through Hole
Termination Post Length (mm [in]) = 3.18 [0.125]
Dimensions:
Height Above PC Board (mm [in]) = 0.00 [0.000]
Body Features:
Row­to­Row Spacing (mm [in]) = 15.24 [0.600]
Mount Style = Vertical
Carrier Strip Material = Mylar
Contact Features:
Socket Style = Standard
Contact Base Material = Beryllium Copper
Contact Plating, Mating Area, Material = Tin­Lead
Contact Style = Screw Machine
Mating Contact Type = Four­Fingered
Housing Features:
Centerline (mm [in]) = 2.54 [0.100]
Configuration Features:
Number of Positions = 40
Number of Patterns Per Reel = 125
Industry Standards:
RoHS/ELV Compliance = RoHS/Not ELV Compliant
Lead Free Solder Processes = Not relevant for lead free process
RoHS/ELV Compliance History = Always was RoHS not ELV compliant
Conditions for Usage:
Temperature Range (°C) = ­55 – +105
Packaging Features:
Packaging Method = Reel
Packaging Quantity = 5,000
Other:
Brand = AMP
Proprietary Name = HOLTITE
