36.83±0.38
32.51±0.25
19.05
13.34
1.905
1.905 typ.
1.27
2.54
0.64
0.70
1.27
2.54
8
Shell: steel, nickel plated
18.0
6.50
Insulator: LCP high temp. thermoplastic,
UL 94V-0 rated, white or black color,
reflow process compatible
Recommended Soldering Temp:
230°C for 30 seconds
260°C max. for 10 seconds
Contact Material: copper alloy
Contact Plating Options:
Standard: gold flash on mating end,
100u" tin-lead on termination
end, with 50u" nickel underplate
on entire contact
30 Option: .000030" [0.00076mm]
gold on mating end, 100u"
tin-lead on termination end,
with 50u" nickel underplate on
entire contact
1
C1
C2
7.72
3.00
5.82
2.51
C3
17
24
C5
C4
1.905
10.4
.0°
15
Ø1.80 typ.
30.73
24.03±0.25
19.05
5.84
1.905 typ.
13.34
1.60
(2) #4-40 UNC
Threaded Inserts
2.34
Rated Current: 1.5A min.
Rated Voltage: 40V DC
2.54
5.08
1.27
1.905 typ.
1
8
C5
C1
C2
Dielectric Withstanding Voltage:
500V (rms) AC for 1 minute
Insulation Resistance:
more than 1000 Megohm at 500V DC
Contact Resistance:
20 milliohm max. initial
10 milliohm max. change from initial
Operating Temperature:
-20°C to +85°C
2.54
17
24
C5
C3
C4
5.18
6.45
5.82
3.30
C3
17
24
C4
C5
6-Ø0.66
1.905
3.81
2.54
1
8
C1
C5
C2
5.08
2.67
24-Ø0.86
4-Ø1.93
19.05
Insertion Force: 4.5kg (10 lbs) max.
Withdrawal Force: 1.0kg (2.2 lbs) min.
Durability: 100 mating cycles
Vibration: no discontinuity >1us
Part Number
KVI-DA29S-FP-B
KVI-DA29S-FP-W
KVI-DA29S-FP-B30
KVI-DA29S-FP-W30
REVISION
DATE
Insulator Color
Black
White
Black
White
DRAWN BY
Contact Area Plating
Gold Flash (standard)
Gold Flash (standard)
30u" Gold (30 option)
30.73
Recommended PCB Layout
(Top View)
R
Tolerances
X.X ± 0.25
X.XX ± 0.15
Unless Stated
Otherwise
30u" Gold (30 option)
REV CHECK BY
UNITS
DATE
C
US
LR78160
DESCRIPTION
REVISED BY
REV CHECK DATE
