26-03-4211 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 26-03-4211

26-03-4211: DescriptionHeaders u0026 Wire Housings KK 156 Crimp Housing Housing Ramp 21 Ckt; CategoryThe connector The connector; File Size58KB，1 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home; Environmental Compliance

Download Datasheet Parametric View All

26-03-4211 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	26-03-4211	-	-	View	Buy Now

26-03-4211 Overview

Headers u0026 Wire Housings KK 156 Crimp Housing Housing Ramp 21 Ckt

26-03-4211 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	POLARISED
body width	0.26 inch
subject depth	0.67 inch
body length	3.308 inch
Body/casing type	PLUG
Connector type	BOARD CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
contact mode	RECTANGULAR
Contact resistance	6 mΩ
Contact style	COMPRESSION
DIN compliance	NO
Dielectric withstand voltage	1000VAC V
Durability	25 Cycles
Filter function	NO
IEC compliance	NO
maximum insertion force	9.7856 N
Insulation resistance	50000000000 Ω
Insulator color	NATURAL
insulator material	NYLON
MIL compliance	NO
Plug contact pitch	.156 inch
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation option 1	LOCKING
Installation method	STRAIGHT
Installation type	CABLE
Number of connectors	ONE
Number of rows loaded	1
Options	GENERAL PURPOSE
Guideline	UL
reliability	COMMERCIAL
Termination type	CRIMP
Total number of contacts	21
UL Flammability Code	94V-2
Base Number Matches	1

Preview

Download Datasheet

View All

This document was generated on 12/11/2017

PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

Part Number:

Status:

Overview:

Description:

0026034211

Active

KK® Interconnect System - Molex

KK 3.96mm Crimp Terminal Housing, Use With Trifurcon Terminals, Friction Ramp, 21

Circuits

Documents:

3D Model

Drawing (PDF)

Product Specification PS-40-02-001 (PDF)

Agency Certification

CSA

General

Product Family

Series

Application

Overview

Product Name

UPC

Physical

Circuits (maximum)

Color - Resin

Flammability

Gender

Glow-Wire Compliant

Lock to Mating Part

Material - Resin

Net Weight

Number of Rows

Packaging Type

Panel Mount

Pitch - Mating Interface

Stackable

Temperature Range - Operating

Solder Process Data

Lead-freeProcess Capability

Material Info

Engineering Number

Reference - Drawing Numbers

Packaging Specification

Product Specification

Sales Drawing

Packaging Specification PK-6442-001-001 (PDF)

RoHS Certificate of Compliance (PDF)

Series image - Reference only

LR19980

Crimp Housings

6442

Power, Wire-to-Board

KK® Interconnect System - Molex

KK 396

800753587137

Natural

94V-2

Receptacle

Yes

Nylon

5.532/g

Bag

3.96mm

See Product Specification

N/A

Mates With

Molex 3.96mm pitch KK headers

6442-R21-Z

PK-6442-001-001

PS-40-02-001

SD-6442

Use With

6838 , 7258 , KK Trifurcon crimp terminals,

45570 MarKK terminal

EU ELV

Not Relevant

EU RoHS

China RoHS

Compliant

REACH SVHC

Not Contained Per -

ED/30/2017 (7 July

2017)

Halogen-Free

Status

Low-Halogen

Need more information on product

environmental compliance?

Email productcompliance@molex.com

Please visit the Contact Us section for any

non-product compliance questions.

China ROHS

ELV

RoHS Phthalates

Green Image

Not Relevant

Not Contained

Search Parts in this Series

6442 Series

This document was generated on 12/11/2017

PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
