1008 CHIP INDUCTORS
Aerospace Grade Chip Inductors
AE413RAM
■
Ferrite construction provides lowest DCR and highest cur-
rent rating of our 1008 size inductors.
■
Available in 14 inductance values from 0.9 to 10 µH, all at
10% tolerance.
This robust version of Coilcraft’s standard 1008AF se-
ries features high temperature materials that pass NASA
low outgassing specifications and allow operation in
ambient temperatures up to 155°C. The leach-resistant
base metalization with tin-lead (Sn-Pb) terminations
ensures the best possible board adhesion.
SRF min
4
(MHz)
415
376
198
135
126
106
70
59
55
48
37
33
34
26
DCR max
5
(Ohms)
0.100
0.105
0.110
0.125
0.140
0.155
0.190
0.210
0.220
0.435
0.280
0.315
0.395
0.480
Isat
6
(A)
1.4
1.3
1.2
1.1
1.0
0.95
0.80
0.75
0.70
0.70
0.55
0.50
0.50
0.45
Imax
(A)
1.3
1.2
1.1
1.0
1.0
0.95
0.90
0.80
0.80
0.65
0.75
0.70
0.65
0.55
Part number
1
AE413RAM901KSZ
AE413RAM112KSZ
AE413RAM132KSZ
AE413RAM152KSZ
AE413RAM192KSZ
AE413RAM222KSZ
AE413RAM272KSZ
AE413RAM332KSZ
AE413RAM392KSZ
AE413RAM472KSZ
AE413RAM582KSZ
AE413RAM682KSZ
AE413RAM822KSZ
AE413RAM103KSZ
Inductance
2
±10% (µH)
0.9
1.1
1.3
1.5
1.9
2.2
2.7
3.3
3.9
4.7
5.8
6.8
8.2
10.0
Q typ
3
25
24
37
22
29
21
22
21
21
27
21
20
20
22
1. When ordering, please specify
testing
code:
AE413RAK103KSZ
Testing: Z
= Coilcraft Critical Products Environmental Stress
Conditions Testing.
H
= Coilcraft Qual + Coilcraft Hi-Rel Burn-in
P
= Coilcraft Qual + MIL-STD-981 Class S Group A
screening
N
= Coilcraft Qual + MIL-STD-981 Class B Group A
screening
C
= Coilcraft Qual + MIL-STD-981 Class S Group A screening
+ MIL-STD-981 Class S Group B qualification
W
= Coilcraft Qual + MIL-STD-981 Class B Group A screening
+ MIL-STD-981 Class S Group B qualification
2. Inductance measured at 2.5 MHz using Coilcraft SMD-A fixture in an
Agilent/HP 4286A impedance analyzer with Coilcraft-provided correlation
pieces.
3. Q measured at 2.5 MHz using an Agilent/HP 4291A with an Agilent/HP
16193 test fixture.
4. SRF measured using an Agilent/HP 8753D network analyzer with a
Coilcraft SMD-D fixture.
5. DCR measured on a Cambridge Technology Micro-ohmmeter.
6. DC current at which the inductance drops 10% (typ.) from its value
without current.
7. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
Core material
Ferrite
Terminations
Tin-lead (63/37) over silver-platinum-glass frit
Ambient temperature
–55°C to +125°C with
Imax
current, +125°C
to +155°C with derated current
Storage temperature
Component: –55°C to +155°C.
Packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Temperature Coefficient of Inductance (TCL)
+100 to +350 ppm/°C
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced crush-resistant packaging
2000 per 7″ reel
Plastic tape: 8 mm wide, 0.3 mm thick, 4 mm pocket spacing,
2.0 mm pocket depth
®
These parts are preproduction products for electrical evaluation only.
Specification subject to change without notice.
Document AE578-1
Revised 06/01/09
1102 Silver Lake Road
Cary IL 60013
© Coilcraft, Inc. 2009
Phone
800-981-0363
Fax
847-639-1508
E-mail
cp@coilcraft.com
Web
www.coilcraft-cps.com
