Printed-circuit board connector - PC 5/ 3-ST2-7,62
7031BDNZ11805 - 1783322
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Plug component, Nominal current: 41 A, Rated voltage (III/2): 1000 V, Number of positions: 3, Pitch: 7.62 mm,
Connection method: Screw connection with tension sleeve, Color: blue grey, Contact surface: Tin
Key Commercial Data
Packing unit
Minimum order quantity
GTIN
GTIN
Custom tariff number
4046356555753
85366990
50 STK
50 STK
Technical data
Dimensions
Pitch
Dimension a
7.62 mm
15.24 mm
General
Range of articles
Type of contact
Number of positions
Connection method
Rated surge voltage (III/3)
Rated surge voltage (III/2)
Rated surge voltage (II/2)
Rated voltage (III/3)
Rated voltage (III/2)
Rated voltage (II/2)
Nominal current I
N
Nominal cross section
Internal cylindrical gage
Stripping length
Screw thread
Tightening torque, min
PC 5/..-ST1
Female connector
3
Screw connection with tension sleeve
8 kV
8 kV
6 kV
1000 V
1000 V
1000 V
41 A
6 mm²
A4
10 mm
M3
0.5 Nm
11/14/2016 Page 1 / 3
https://www.phoenixcontact.com/hq/products/1783322
Printed-circuit board connector - PC 5/ 3-ST2-7,62
7031BDNZ11805 - 1783322
Technical data
General
Tightening torque max
0.8 Nm
Connection data
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Conductor cross section flexible, with ferrule without plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve max.
Conductor cross section AWG min.
Conductor cross section AWG max.
2 conductors with same cross section, solid min.
2 conductors with same cross section, solid max.
2 conductors with same cross section, stranded min.
2 conductors with same cross section, stranded max.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, min.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, max.
2 conductors with same cross section, stranded, TWIN ferrules with
plastic sleeve, min.
2 conductors with same cross section, stranded, TWIN ferrules with
plastic sleeve, max.
Minimum AWG according to UL/CUL
Maximum AWG according to UL/CUL
0.2 mm²
10 mm²
0.2 mm²
6 mm²
0.25 mm²
0.25 mm²
4 mm²
24
10
0.2 mm²
2.5 mm²
0.2 mm²
4 mm²
0.25 mm²
1.5 mm²
0.25 mm²
2.5 mm²
24
8
Conductor cross section flexible, with ferrule without plastic sleeve max. 6 mm²
Standards and Regulations
Connection in acc. with standard
CUL
Environmental Product Compliance
China RoHS
Environmentally Friendly Use Period = 50
For details about hazardous substances go to tab “Downloads”,
Category “Manufacturer's declaration”
Approvals
Approvals
Approvals
UL Recognized / cUL Recognized / EAC / cULus Recognized
11/14/2016 Page 2 / 3
https://www.phoenixcontact.com/hq/products/1783322
Printed-circuit board connector - PC 5/ 3-ST2-7,62
7031BDNZ11805 - 1783322
Approvals
Ex Approvals
Approval details
UL Recognized
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm FILE E 60425
cUL Recognized
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm FILE E 60425
EAC B.01742
cULus Recognized
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
Phoenix Contact 2016 © - all rights reserved
http://www.phoenixcontact.com
11/14/2016 Page 3 / 3
