STEVAL-MKI075V1
LY3100ALH adapter board designed for
a standard DIL24 socket
Data brief
Features
■
■
■
Complete LY3100ALH pinout in standard DIL
24 socket
Fully compatible with all other available
adapter boards
RoHS compliant
Description
The STEVAL-MKI075V1 is an adapter board
designed to facilitate the evaluation of the
LY3100ALH product family. The board offers an
effective solution for fast system prototyping and
device evaluation directly within the user’s own
application.
The STEVAL-MKI075V1 can be plugged into a
standard DIL 24 socket. The adapter provides the
complete LY3100ALH pinout and comes ready-to-
use with the required decoupling capacitors on
the V
DD
power supply line.
The pinout of the adapter is fully compatible with
all other available adapter boards, making it
possible to easily switch from one sensor to
another during device evaluation without the need
for board redesign.
STEVAL-MKI075V1
September 2010
Doc ID 17920 Rev 1
1/4
www.st.com
4
