IPC0089-S
Datasheet revision 1.0
www.Proto-Advantage.com
DFN-22 Stencil (0.5 mm pitch, 6.0 x 5.0 mm body)
DIMENSIONS
REF.
A
B
C
B2
C2
D
D2
E
MIN.
mm
TYP.
4.00
0.70
0.25
2.60
5.40
0.25
0.70
0.50
MAX.
MIN.
inches
TYP.
MAX.
Top View (SMT Footprint)
A
B
C
E
D
C2
B2
D2
(Representative drawing only - not to scale)
