TimeFlash
General Description
Programmer for PureSilcon™ Oscillators
Features
Small dongle interfaces through USB
to PC
Automatic software upgrades via
Internet
Field Programmable Dongle for
o
DSC8001 – Standard CMOS
o
DSC8002 – Standard CMOS
o
DSC8101 – Performance CMOS
o
DSC8102 – Performance LVPECL
o
DSC8103 – Performance LVDS
o
DSC8104 – Performance HCSL
o
DSC8121 - Performance CMOS
o
DSC8122 – Performance LVPECL
o
DSC8123 – Performance LVDS
o
DSC8124 – Performance HCSL
Socket Adapter Cards Support:
o
2.5 x 2.0 x 0.85 mm
o
3.2 x 2.5 x 0.85 mm
o
5.0 x 3.2 x 0.85 mm
o
7.0 x 5.0 x 0.85 mm
The TimeFlash programmer allows users to
rapidly program, through a Microsoft Windows
GUI program on a PC, any DSC8XXX
Programmable MEMS oscillator to a custom
frequency in seconds. Timeflash supports the
field programmable versions of the DSC10XX
Standard CMOS and the DSC11XX Performance
oscillators. The oscillators can be programmed
over their respective frequency range in
increments of 100Hz.
The TimeFlash programming kit includes a
programming dongle, USB cable, antistatic
tweezers and USB flash drive with a Windows
based PC installation program. The TimeFlash
is used with device dependent socket adapter
cards and the appropriate DSC8XXX devices.
Available in industry standard packages, the
DSC8XXX can be “dropped-in” to the same PCB
footprint as standard crystal oscillators.
All Rights Reserved. No part of this document may be copied or reproduced in any form without the prior written permission of Discera, Inc. Discera Inc. may update or make
changes to the contents, products, programs or services described at any time without notice. This document neither states nor implies any kind of warranty, including, but not
limited to implied warranties of merchantability or fitness for a particular use.
Page 1
MK-Q-B-P-D-050610-01-4
TimeFlash
TimeFlash Specifications
Programmer Power Supply
Oscillator Operating Supply Voltage
Programming Time
Operating System Supported
Programmer Size
Programmer Weight
Programmer for PureSilcon™ Oscillators
Supplied thru USB Cable ( micro USB to USB A)
1.8 v 3.6 v
2 Seconds
MS Windows (XP, Vista & Windows 7) 32 or 64 bit
compatible
2
1/2
" X 1
1/4
" X
1/2
"
0.2 lb
Socket Adapter Kits
Item
DSC-PROG-8001-2520
DSC-PROG-8001-3225
DSC-PROG-8001-5032
DSC-PROG-8001-7050
DSC-PROG-8002-2520
DSC-PROG-8002-3225
DSC-PROG-8002-5032
DSC-PROG-8002-7050
DSC-PROG-81x1-2520
DSC-PROG-81x1-3225
DSC-PROG-81x1-5032
DSC-PROG-81x1-7050
DSC-PROG-81x2-2520
DSC-PROG-81x2-3225
DSC-PROG-81x2-5032
DSC-PROG-81x2-7050
DSC-PROG-81x3-2520
DSC-PROG-81x3-3225
DSC-PROG-81x3-5032
DSC-PROG-81x3-7050
Description
Kit includes 2.5x2.0mm socket adapter &
50
blank DSC8001DI2 oscillators at 25ppm/-40C to +85 C
Kit includes 3.2x2.5mm socket adapter &
50
blank DSC8001CI2 oscillators at 25ppm/-40C to +85 C
Kit includes 5.0x3.2mm socket adapter &
50
blank DSC8001BI2 oscillators at 25ppm/-40C to +85 C
Kit includes 7.0x5.0mm socket adapter &
50
blank DSC8001AI2 oscillators at 25ppm/-40C to +85 C
Kit includes 2.5x2.0mm socket adapter &
50
blank DSC8002DI2 oscillators at 25ppm/-40C to +85 C
Kit includes 3.2x2.5mm socket adapter &
50
blank DSC8002CI2 oscillators at 25ppm/-40C to +85 C
Kit includes 5.0x3.2mm socket adapter &
50
blank DSC8002BI2 oscillators at 25ppm/-40C to +85 C
Kit includes 7.0x5.0mm socket adapter &
50
blank DSC8002AI2 oscillators at 25ppm/-40C to +85 C
Kit includes 2.5x2.0mm socket adapter &
5
blank DSC81x1DI2 (Standby or Enable High CMOS at 25ppm/-40C to +85 C)
Kit includes 3.2x2.5mm socket adapter &
5
blank DSC81x1CI2 (Standby or Enable High CMOS at 25ppm/-40C to +85 C)
Kit includes 5.0x3.2mm socket adapter &
5
blank DSC81x1BI2 (Standby or Enable High CMOS at 25ppm/-40C to +85 C)
Kit includes 7.0x5.0mm socket adapter &
5
blank DSC81x1AI2 (Standby or Enable High CMOS at 25ppm/-40C to +85 C)
Kit includes 2.5x2.0mm socket adapter &
5
blank DSC81x2DI2 (Standby or Enable High LVPECL at 25ppm/-40C to +85 C)
Kit includes 3.2x2.5mm socket adapter &
5
blank DSC81x2CI2 (Standby or Enable High LVPECL at 25ppm/-40C to +85 C)
Kit includes 5.0x3.2mm socket adapter &
5
blank DSC81x2BI2 (Standby or Enable High LVPECL at 25ppm/-40C to +85 C)
Kit includes 7.0x5.0mm socket adapter &
5
blank DSC81x2AI2 (Standby or Enable High LVPECL at 25ppm/-40C to +85 C)
Kit includes 2.5x2.0mm socket adapter &
5
blank DSC81x3DI2 (Standby or Enable High LVDS at 25ppm/-40C to +85 C)
Kit includes 3.2x2.5mm socket adapter &
5
blank DSC81x3CI2 (Standby or Enable High LVDS at 25ppm/-40C to +85 C)
Kit includes 5.0x3.2mm socket adapter &
5
blank DSC81x3BI2 (Standby or Enable High LVDS at 25ppm/-40C to +85 C)
Kit includes 7.0x5.0mm socket adapter &
5
blank DSC81x3AI2 (Standby or Enable High LVDS at 25ppm/-40C to +85 C)
Ordering Information
PART #
DSC Prog TimeFlash
KIT CONTENTS
Kit includes TimeFlash programmer, USB cable, tweezers, Quick Start guide & Installation USB Flash drive
For programming of devices, a TimeFlash programmer and an appropriate adapter card kit are required.
DISCERA, Inc.
Phone: +1 (408) 432-8600
1961 Concourse Drive,
Fax: +1 (408) 432-8609
San Jose, California
95131
Email: sales@discera.com
USA
www.discera.com
